3Dresyn Bioflex D60 MB Monomer Based

Flexible biocompatible monomer-based 3D printing resin (Shore D60)

Product description

3Dresyn® Bioflex D60 MB is a biocompatible monomer-based photopolymer resin designed to provide increased flexibility and medium Shore D hardness (D60), while maintaining good dimensional stability and very high printing resolution.

The monomer-based formulation offers broader processing latitude and robust printability across a wide range of vat photopolymerization systems, supporting reliable calibration and repeatable results.

Intended use

Intended for professional use in vat photopolymerization (SLA, DLP and LCD) additive manufacturing systems operating in the 385–405 nm range.

Final suitability of printed parts must be validated by the user according to the specific application, processing conditions and applicable regulatory requirements.

Typical applications

• Flexible structural and technical components requiring medium hardness
• Wearable development prototypes
• Flexible yet durable functional parts
• Dynamic mechanical models
• Application-dependent systems requiring controlled flexibility

Material properties & test methods

Mechanical properties

• Shore hardness: D60 (ISO 868)
• Tensile strength: < 25 MPa (typical) (ISO 527-1 / ISO 527-2)
• Tensile modulus (Young’s modulus): < 1000 MPa (typical) (ISO 527-1 / ISO 527-2)
• Elongation at break: < 70 % (typical) (ISO 527-1 / ISO 527-2)
• Flexural strength: < 25 MPa (typical) (ISO 178)

Thermal properties

• Heat deflection temperature (HDT): < 50 °C @ 0.45 MPa (typical) (ISO 75)

Physical properties

• Density: 1.0–1.2 g/cm³ (typical) (ISO 1183)
• Water absorption: < 0.1 % (typical, 24 h @ 23 °C) (ISO 62)
• Shrinkage: low (process dependent)

Biocompatibility & quality framework

• Biocompatibility evaluated according to ISO 10993 (post-cured and properly cleansed specimens)
• Manufacturing aligned with ISO 13485 quality management systems
• Biological performance depends on final printing, cleaning and post-curing workflow

Printing & processing guidelines

• Printing technologies: SLA, DLP and LCD
• Wavelength range: 385–405 nm
• Proper washing and post-curing are required to achieve final mechanical properties and biocompatibility outcomes
• Material behavior depends on printer, parameters, geometry, washing, post-curing and workflow control

Product units

Available units: 500 g, 1,000 g

Testing & processing disclaimer

Material properties are measured on printed and post-processed specimens and may vary depending on the selected material version, printer type, printing parameters, build orientation, post-curing conditions and specimen preparation. Reported values are indicative and provided for reference only.

Regulatory & legal notice

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. The regulatory classification, conformity assessment and validation of any final device manufactured using this material remain the sole responsibility of the legal manufacturer.

Why choose 3Dresyn® Bioflex D60 MB

• Medium hardness flexible system (Shore D60)
• Biocompatible monomer-based formulation
• Broader processing latitude and robust printability
• Very high resolution and low shrinkage behaviour
• Designed for professional additive manufacturing workflows
• Technical and regulatory support available upon request

Document reference: TDS-BIOFLEX-D60-MB-EN | Version: 2.0 | Last updated: March 2026
