3Dresyn Photo-Wax, our safe scannable dental impression photocurable wax

Product description

3Dresyn Photo-Wax is our safe scannable dental impression photocurable wax for making dimensional stable rigid dental impressions of complete dentures.

It is a photo reactive soft wax which before curing can be modelled by hand but after bite registration can be hardened in the mouth with a normal UV/Visible light source for maximum impression accuracy.

Application framework

Designed for dental impression workflows requiring a safe scannable photocurable wax for complete dentures and related bite registration procedures in controlled professional environments.

Typical applications

• Dental impressions of complete dentures
• Bite registration
• Scannable dental impressions

Measured mechanical properties

• Shore hardness: O50/A90 b/a (ISO 868)

Measured physical properties

• Melting temperature as supplied before printing: 30-35ºC
• Melting temperature after photo curing: 45-50ºC

Functional performance characteristics

• Safe scannable dental impression photocurable wax
• Soft before photocuring for easy impression and bite registration with minor pressure to avoid distortion
• Hard and rigid impressions without flexibility after photocuring
• Fast photo curing in the mouth which can be hardened even more out of the mouth under sunlight or in a light box
• Ideal for optimum scanning detail and resolution
• Ultra safe, free of hazards, pictograms and risk phrases
• Soft, easy to shape with hand pressure for optimum application
• Dimensional stability
• Easy cutting
• Long shelf life
• Neutral taste, non acidic, non alkaline

Processing and handling performance

• Photo reactive soft wax with Shore O50 before curing
• After photo curing becomes harder with a Shore hardness of A90
• Its rigidity is ideal to prevent distortion of the impression borders, having good accuracy of surface detail and dimensional stability
• Safe biocompatible yellowish white soft wax
• Scannable with maximum resolution due to its matt finish, ensuring maximum detail of the scans
• Photocurable with standard dental lab light curing units

Chemical and safety characteristics

• Safe biocompatible
• Ultra safe, free of hazards, pictograms and risk phrases
• Neutral taste, non acidic, non alkaline

Testing & processing disclaimer

Final impression accuracy, scanning resolution, dimensional stability and suitability for the intended dental workflow depend on application thickness, curing conditions, handling protocol and full processing workflow, and must be validated by the user.

Disclaimer

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

Document reference: TDS-3DRESYN-PHOTO-WAX-EN | Version: 1.0 | Last updated: March 2026
