3D-ADD Disper-All3 WS, ultra effective dispersant for water and solvent soluble systems

Product description

3D-ADD Disper-All3 WS is a low viscosity high polarity dispersant for water and solvent soluble resin systems.

It is designed as a water and solvent soluble wetting agent and dispersant for a broad range of organic, inorganic, ceramic and metal nano and micro powders, as well as wires and fibers. It is particularly suitable for high polarity systems and conductive 3D resins.

Application framework

Designed for use in water and solvent soluble resin systems, including high polarity systems and conductive 3D resins. Compatible with most of our SLA, DLP, LCD and Inkjet 3Dresyns.

Typical applications

• Wetting and dispersing organic, inorganic, ceramic and metal nano and micro powders
• Wetting and dispersing wires and fibers
• Making ultra high concentration dispersions of pigments, fillers, ceramics and metals
• Wetting substrates and improving intercoat adhesion

Measured physical properties

• Low viscosity high polarity dispersant
• Light yellow color
• Resistance 288 Ohm/sq
• Resistivity: 144 mOhm.m
• Conductivity: 7 S/m
• Ideal for making ultra high concentration of pigments, fillers, ceramics and metals dispersions of up to 90% by weight powder solids with good flow
• Optimum dosage between 1-10% on powder solids for wetting and dispersing powder pigments, fillers, ceramics and metals
• Powder additions up to 90% by weight concentrations can be made still with good flow for low oil absorption and surface area powders, wires, and fibers
• Relative low viscosity with good flow and long term stability

Functional performance characteristics

• High polarity, ideal for high polarity systems and conductive 3D resins
• Excellent general usage ultra effective water and solvent soluble wetting agent and dispersant
• Excellent wetting and dispersion yield, stability and flow of post added micron and submicron "nano" powders, wires, and fibers
• Water and solvent soluble with certain turbidity and high dosage

Processing and handling performance

• Compatible with most of our SLA DLP, LCD and Inkjet 3Dresyns
• Ideal for wetting substrates and improving intercoat adhesion
• Non photoreactive
• It is supplied as a kit, which contains the product, one graduated beaker and one empty 250 mL black bottle to measure, mix, keep and protect the 3D resins from daylight
• Please do not expose any 3D resins to natural or room light to prevent their curing.

Chemical and safety characteristics

• Biodegradable
• Safe for handling and final users

Testing & processing disclaimer

Please do not expose any 3D resins to natural or room light to prevent their curing.

Disclaimer

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

Document reference: TDS-3D-ADD-DISPER-ALL3-WS-EN | Version: 1.0 | Last updated: March 2026
