3D-PAINT GrapEK2 Bio is our biocompatible electrically conductive nano graphene water based paint for painting 3D printed high conductivity materials for electronics e.g. antennas for IoT applications (HF, UHF), RFID and NFC tags, OLED, OPVs, flexible PCBs, flexible cables, etc...
It is a biocompatible "safe" nano graphene water based paint which provides high conductivity to our 3Dresyns, after post curing them at low drying temperature.
Typical values of 3D-PAINT GrapEK2 Bio:
- drying T: at room temperature for 10 minutes or at 50ºC for 5 minutes
- Sheet resistance <60 Ω/sq
Features of 3D-PAINT GrapEK2 Bio*:
- electrically conductive biocompatible and biodegradable water based nano graphene paint
- excellent conductivity when used pure or diluted with water by brushing or dip coating on the surface of 3D printed parts
- viscous paint which can be custom diluted with water to adjust its viscosity, flow and surface smoothness
- ideal for dipping 3D prints in 3D-PAINT GrapEK2 Bio diluted in water for cost effectiveness
- adjust the viscosity of 3D-PAINT forms a resistant film which has excellent adhesion on the surface of most 3D printed 3Dresyns
3D-PAINT GrapEK2 Bio is supplied as a kit, which contains 3D-PAINT GrapEK2 Bio and one graduated beaker for custom viscosity adjustment with water when used as dip coating of your 3D printed parts.
*Note: It is highly recommended to apply 3D-PAINT GrapEK2 Bio by brushing or dipping 3D printed parts diluted as you wish with water at pH 7.
IMPORTANT: The product if stored at room temperature (<25˚C) has a shelf life of 6 months. If stored well sealed at 4ºC in a fridge its shelf life can be extended longer. 3Dresyns cannot assume responsibility for a conductive product that has not been stored in appropriate conditions. Orders will be made to order to maximise the shelf life of the product. Its delivery time is around 2 weeks after ordering.
