4Dresyn TF-LV1, Tough & Foldable Low Viscosity 4D resin

Product description

4Dresyn® TF-LV1 is a tough and foldable low viscosity 4D photopolymer designed to exhibit temperature-dependent mechanical behavior, transitioning from rigid below 10 °C to tough and flexible above 20 °C. It is intended to be combined with other 4Dresyn® materials to achieve customized 4D performance and programmed mechanical response.

Application framework

Designed for use in SLA, DLP and LCD vat photopolymerization systems within controlled professional environments. Suitable for multi-material 4D printing applications requiring temperature-triggered flexibility, shape adaptation or responsive mechanical behavior.

Typical applications

• 4D printing systems with low-temperature activation
• Flexible structures activated above room temperature
• Shape-morphing or adaptive components
• Hydrophobic functional parts with low water absorption
• Smart material prototypes with programmed response

Measured mechanical properties

• Thermal transition range: ~10–20 °C
• Tensile strength: <30 MPa (ISO 527)
• Flexural strength: <30 MPa (ISO 178)
• Young’s modulus: <600 MPa (ISO 527)
• Shore hardness: D80 (ISO 868)
• Elongation: <70% (ISO 527)
• Typical viscosity: <10–20 mPa·s at 25 °C

Functional performance characteristics

• Rigid behavior below 10 °C
• Tough and foldable behavior above 20 °C
• Designed for combination with other 4Dresyn® materials
• Extremely low viscosity for high processability
• Hydrophobic ULWA (Ultra Low Water Absorption) grade
• Clear, non-yellowing appearance
• Biocompatible-grade formulation with safe handling profile
• Durable performance under controlled conditions
• Very low shrinkage
• Organo-tin free formulation
• Compatible with most SLA, DLP and LCD 3D printers

Processing and handling performance

• Ultra-low viscosity resin enabling fast recoating and high detail resolution
• Designed for blending with other 4Dresyn® systems to tune transition behavior
• Compatible with standard vat photopolymerization workflows
• Suitable for high-resolution and low-force printing systems

Testing & processing disclaimer

Material performance depends on printer type, exposure conditions, geometry, post-processing and multi-material formulation. Functional 4D behavior must be validated by the user under the intended thermal and mechanical conditions.

Why choose 4Dresyn® TF-LV1

• Low-temperature responsive rigid-to-flexible transition
• Ultra-low viscosity for excellent printability
• Tough and foldable performance above transition temperature
• Hydrophobic ULWA grade with low water absorption
• Clear, non-yellowing appearance
• Compatible with standard SLA, DLP and LCD printers
• Durable and organo-tin free formulation
• Safe handling profile when properly processed

Regulatory & legal notice

This material is supplied as a professional manufacturing material and is not marketed as a finished product. Safe use requires appropriate personal protective equipment. Final performance, actuation behavior and application suitability remain the responsibility of the user.

Document reference: TDS-4DRESYN-TF-LV1-EN | Version: 1.0 | Last updated: March 2026
