Thinner 3Dresyn TF Bio, tough & foldable biocompatible reactive diluent

Thinner 3Dresyn TF Bio is a tough & foldable reactive diluent or thinner with deflection temperature c. 20ºC.

Thinner 3Dresyn TF Bio has extremely low viscosity and excellent viscosity reduction while imparting toughness and foldability in compatible SLA, DLP & LCD 3D resin systems.

Designed for use as a tough & foldable reactive diluent or thinner in compatible SLA, DLP & LCD 3D resin systems.

• Reducing viscosity of compatible 3D resin systems
• Formulating tough and foldable 3D resin systems

• Tensile strength: <10 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <10 MPa (ISO 178)
• Young’s modulus: <10 MPa (ISO 527)
• Elongation at break: <70% (ISO 527)
• Shore hardness: D40 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Viscosity: <20 mPas at 23°C ± 2°C (ISO 3219)
• Deflection temperature: c. 20ºC (ISO 75)
• Clear, non yellowing
• Very low shrinkage

• Imparts toughness and foldability
• Durable

• Printable by most commercial and professional SLA, DLP & LCD 3D printers

• Biocompatible
• Synthetic resin source
• Hydrophobic, ultra low water absorption ULWA grade
• Organo-tin free

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.

Access the 3Dresyns® Technical Resources (IFU, calibration, CRT, post-processing and troubleshooting)
