3D-ADD HDT1 Bio, biocompatible Heat Deflection Temperature booster for custom increase of HDT

Product description

3D-ADD HDT1 Bio is a biocompatible Heat Deflection Temperature booster for custom rigidity refinement of 3Dresyns.

It is designed for custom boosting the HDT of 3Dresyns and is normally used at 5-10% dosage or more depending on HDT specifications for certain thickness.

Application framework

Designed for use with 3Dresyns systems to increase Heat Deflection Temperature and refine rigidity in compatible photopolymer formulations.

Typical applications

• Custom boosting the HDT of 3Dresyns
• Custom rigidity refinement of 3Dresyns

Measured mechanical properties

• Tensile strength: <70 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: < 140 MPa (ISO 178)
• Young’s modulus: < 10.000 MPa (ISO 527)
• Elongation at break: < 1 % (ISO 527)
• Impact resistance, Notched Izod: <15 J/m (ISO 180:2023)
• Shore hardness: D90 ± 2 (ISO 868)

Measured thermal properties

• Heat deflection temperature (HDT): <290 °C @ 0.45 MPa (ISO 75)

Measured physical properties

• Viscosity: < 4000 mPas at 23°C ± 2°C (ISO 3219)
• Density: 1.0-1.2 g/cm³ (ISO 1183)
• Water absorption: < 0.01 % (24 h at 23°C) (ISO 62)

Functional performance characteristics

• Ultra effective booster of HDT
• Ultra fast curing
• Ultra rigid at room and at high temperature
• Excellent chemical resistance
• Durable

Processing and handling performance

• It is supplied as a kit, which contains the product, one graduated beaker and one empty 250 mL black bottle to measure, mix, keep and protect the 3D resins from daylight
• Please do not expose any 3D resins to natural or room light to prevent their curing.
• 3D-ADD HDT1 Bio is normally used up to 5-10% dosage (or more depending on HDT specifications for certain thickness)

Chemical and safety characteristics

• Biocompatible
• Organo-tin free

Testing & processing disclaimer

High Heat Deflection Temperature HDT 3D resins despite being rigid tend to be fragile and have a short lifetime, degrading thermally at high temperature.

Disclaimer

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

Document reference: TDS-3D-ADD-HDT1-BIO-EN | Version: 1.0 | Last updated: March 2026
