3D Cement OCA, Light Curable Opaque Cement Composite & Adhesive in Tooth colors A1-4, B1-4, C1-4, D2-4 & Bleach BL1

3D Cement OCA is a light curable Opaque Cement Composite & Adhesive in tooth colors A1-4, B1-4, C1-4, D2-4 & Bleach BL1. It is ideal for cementing and gluing teeth with the most common shades of tooth colors.

This material is intended for light curable cementing before fixing veneers and as a light curable resin composite for durable dental fillings. It is a viscous non flowing paste designed for easy application and durable performance.

Designed for light curable cementing and gluing applications in the most common shades of tooth colors. Curable with light from 150 to 420 nm (UV & Visible spectrum).

• Light curable cementing before fixing veneers
• Cementing and gluing teeth with the most common shades of tooth colors
• Durable dental fillings

• Tensile strength >40 MPa (ISO 527-1 / ISO 527-2)
• Elongation at yield <3% (ISO 527)
• High hardness, Shore hardness D85-90 (ISO 868)
• Very high flexural strength >120 MPa (ISO 178 / ISO 4049)
• High rigidity (Young modulus 2700-3300 MPa) (ISO 527)

• Water solubility: ≤ 1,6 µg/mm3 (ISO 4049)
• Curable with light from 150 to 420 nm (UV & Visible spectrum)
• Excellent opacity and hiding power
• Viscous non flowing paste with no sagging or dripping out
• Very low shrinkage
• Hydrophobic, ultra low water sorption ULWA≤ 32 µg/mm3 (ISO 4049)

• Durable and resistant light curable cement composite
• Ultra fast curing in seconds with most dental lights
• Excellent adhesive properties
• Similar mechanical properties to PEEK but with improved chemical resistance
• Superior durability, mechanical properties and abrasion resistance
• Excellent adhesion to most commonly used dental materials and primers
• Excellent light fastness

• Available in all tooth colors A1-4, B1-4, C1-4, D2-4 & Bleach BL1
• Easy application with a brush or spatula
• Color matching has been undertaken for postcured prints
• It is ideal to custom control the postcuring time in your light box, since each light box has different wavelength and power, until the reaching the desired tooth shade
• Too long and too powerful light box postcuring can increase a bit the darkness of translucent shades
• Do not expose 3D Cement OCA to natural or room light to prevent their curing

• Organo-tin free
• Fully compliant with the Quality requirements of FDA, ISO 20795, 13485 & 10993

Color shades are approximate and may be affected by printing and postcuring specifications beyond our control.

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
