3Dresyn Biotough D90 MF Monomer Free

Product description

3Dresyn® Biotough D90 MF is a tough, high-rigidity, monomer-free biocompatible photopolymer engineered to provide improved resistance to cracking and mechanical shock compared to ultra-rigid grades.

The material combines dimensional stability with enhanced toughness, making it suitable for demanding engineering and regulated manufacturing environments where mechanical reliability is critical.

Application framework

Intended for professional use in vat photopolymerization (SLA, DLP and LCD) additive manufacturing systems operating in the 385–405 nm range.

Final suitability of printed parts must be validated by the user according to the specific application, processing conditions and applicable regulatory requirements.

Typical applications

• High-strength structural components
• Impact-resistant fixtures and positioning tools
• Load-bearing prototypes in regulated development workflows
• Durable anatomical and technical models

Measured mechanical properties

• Tensile strength: 40–60 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: 60–90 MPa (ISO 178)
• Young’s modulus: 2200–2800 MPa (ISO 527-1 / ISO 527-2)
• Elongation at break: 5–10 % (ISO 527-1 / ISO 527-2)
• Shore hardness: D90 (ISO 868)

Measured thermal properties

• Heat deflection temperature (HDT): >120 °C @ 0.45 MPa (ISO 75)
• Viscosity of HV version: <10000 mPas at 23°C ± 2°C (ISO 3219)
• Viscosity of LV version: <5000 mPas at 23°C ± 2°C (ISO 3219)


Measured physical properties

• Density: 1.0–1.2 g/cm³ (ISO 1183)
• Water absorption: <0.1 % (24 h @ 23 °C) (ISO 62)
• Shrinkage: very low

Functional performance characteristics

• Tough, high-rigidity system
• Improved resistance to cracking and mechanical shock compared to ultra-rigid grades
• Good dimensional stability
• Designed for demanding engineering and regulated workflows
• Monomer-free biocompatible formulation

Processing and handling performance

• Printing technologies: SLA, DLP and LCD
• Wavelength range: 385–405 nm
• Proper washing and post-curing are required to achieve final mechanical properties and biocompatibility outcomes
• Material behavior depends on printer, parameters, geometry, washing, post-curing and workflow control
• Available units: 500 g, 1,000 g

Chemical and safety characteristics

• Monomer-free system architecture designed to minimize residual extractables after proper post-processing

Biocompatibility framework

• Biocompatibility evaluated according to ISO 10993 on post-cured and properly cleansed specimens
• Manufacturing aligned with ISO 13485 quality management systems

Testing & processing disclaimer

Material properties are measured on printed and post-processed specimens and may vary depending on the selected material version, printer type, printing parameters, build orientation, post-curing conditions and specimen preparation. Reported values are indicative and provided for reference only.

Disclaimer

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. The regulatory classification, conformity assessment and validation of any final device manufactured using this material remain the sole responsibility of the legal manufacturer.

Document reference: TDS-BIOTOUGH-D90-MF-EN | Version: 2.0 | Last updated: March 2026
