3Dresyn GrapSEK1-MWCNT Bio Water-Soluble Conductive Resin (Bio)

3Dresyn® GrapSEK1-MWCNT Bio is a biocompatible, electrically and thermally conductive photopolymer based on multi-wall carbon nanotube (MWCNT) technology. It is designed as a ready-to-print conductive resin with controlled water solubility after printing, enabling both functional conductive parts and sacrificial conductive structures.

This formulation combines high conductivity nanocomposite performance with water-soluble behavior, supporting advanced additive manufacturing strategies including removable conductive pathways and embedded electronics.

Designed for use in vat photopolymerization systems (SLA, DLP and LCD) within research, development and industrial environments focused on conductive materials, functional devices and advanced manufacturing workflows.

• 3D printed conductive tracks and interconnects
• Sacrificial conductive structures for embedded electronics
• Temporary conductive pathways and supports
• Functional electronic components and sensors
• Research in conductive nanocomposite materials

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Resolution capability: high (process-dependent)
• Viscosity: optimized within the processing range required for the intended printing process and application
• Material type: MWCNT-based conductive nanocomposite
• Solubility: water soluble after printing
• Cleaning: water washable and dissolvable

• Resistivity: <0.1 – 100 Ω·cm (ISO 3915)
• Sheet resistance: <0.004 – 4 kΩ/square (250 µm films)
• Conductivity: >1 – 1000 mS/m

• Ready-to-use conductive resin with integrated MWCNT network
• High electrical and thermal conductivity
• Biocompatible-grade formulation (final part validation required)
• Water-soluble behavior enabling sacrificial applications
• Suitable for fabrication of removable conductive geometries
• High resolution and fine feature capability
• Supports advanced manufacturing strategies with embedded or temporary conductive elements

• Compatible with SLA, DLP and LCD 3D printing systems
• Recommended layer thickness: <20–40 µm depending on printer power
• Excellent printability across a wide range of systems*
• Water-cleanable and dissolvable post-processing workflow
• Requires optimized exposure parameters for conductive performance
• Specific IFU recommended for each printer and application

This product has a guaranteed shelf life of 6 months when stored between 15–25 °C. In practice, longer storage may be possible under controlled conditions.

• Biocompatible-grade formulation
• Nanocomposite system containing multi-wall carbon nanotubes
• Organo-tin free formulation

Electrical performance depends on geometry, printing parameters, layer thickness, dispersion quality and post-processing conditions. Conductivity values are indicative and must be validated by the user for each specific application.

This material is supplied as a professional functional material for research, development and manufacturing workflows. It is not marketed as a finished electronic or medical device. Final performance and suitability must be validated by the user.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
