3Dresyn IM-HF, durable, hard and flexible for injection of soft materials

3Dresyn® IM-HF is a hard and flexible photopolymer developed for the fabrication of durable components requiring a combination of toughness, flexibility and high resolution.

Designed for use in vat photopolymerization systems (SLA, DLP and LCD) within controlled professional environments. Suitable for applications requiring flexible yet mechanically resistant structures capable of deformation without fracture.

• Flexible and durable functional parts
• Foldable structures and components
• Impact-resistant elements
• Prototyping of elastomer-like rigid parts
• Applications requiring combined toughness and flexibility

• Tensile strength: <20 MPa (ISO 527)
• Flexural strength: <20 MPa (ISO 178)
• Young’s modulus: <100 MPa (ISO 527)
• Elongation: <100% (ISO 527)
• Shore hardness: A90 (ISO 868)
• Medium viscosity (Brookfield)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Viscosity: optimized within the processing range required for the intended printing process and application

• Hard and flexible behavior
• 100% foldable without breaking
• Very high printing resolution (<20 µm)
• Very low shrinkage

• Printable by most commercial and professional SLA, DLP and LCD 3D printers
• Increased durability of the resin tank
• Organo-tin free formulation

Material performance depends on printer type, exposure conditions, geometry and full workflow implementation. Mechanical performance must be validated by the user for each specific application.

• Unique combination of hardness and flexibility
• Foldable without fracture
• High resolution and dimensional stability
• Suitable for functional and durable applications
• Compatible with SLA, DLP and LCD technologies

This material is supplied as a professional manufacturing material and is not marketed as a finished product. Final performance and process validation remain the responsibility of the user depending on printer, geometry and workflow conditions.
