3Dresyn IM-HF MF Bio, Biocompatible, durable, hard and flexible, monomer free, for injection of biocompatible soft materials

3Dresyn® IM-HF MF Bio is a hard and flexible monomer-free photopolymer developed for the fabrication of biocompatible components requiring a combination of toughness, flexibility and high resolution.

• Flexible and durable biocompatible components
• Foldable structures and devices
• Medical and dental auxiliary components
• Prototyping of elastomer-like rigid parts
• Applications requiring combined toughness and flexibility

• Tensile strength: <20 MPa (ISO 527)
• Flexural strength: <20 MPa (ISO 178)
• Young’s modulus: <100 MPa (ISO 527)
• Elongation: <100% (ISO 527)
• Shore hardness: A90 (ISO 868)
• Medium viscosity: <10,000 mPas at 23°C ± 2°C (ISO 3219)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)

• Hard and flexible behavior
• Monomer-free formulation
• Biocompatible material system
• 100% foldable without breaking
• Very high printing resolution (<20 µm)
• Very low shrinkage

• Printable by most commercial and professional SLA, DLP and LCD 3D printers
• Increased durability of the resin tank

Material performance depends on printer type, exposure conditions, geometry and full workflow implementation. Biocompatibility must be validated on the final printed and post-processed part according to the intended application.

• Monomer-free and biocompatible formulation
• Unique combination of hardness and flexibility
• Foldable without fracture
• High resolution and dimensional stability
• Suitable for medical and technical applications
• Compatible with SLA, DLP and LCD technologies

This material is supplied as a professional manufacturing material and is not marketed as a finished product. Final performance, biocompatibility and process validation remain the responsibility of the user depending on printer, geometry and workflow conditions.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
