3Dresyn NMF HAR1 Bio, Biocompatible High Aspect Ratio ultra rigid photopolymer for nano and micro fabrication

3Dresyn NMF HAR1 Bio is a UV & EB curable organic high aspect ratio and ultra rigid photopolymer for nano and micro fabrication, including printing of ultra rigid stamps for Nano Imprinting lithography NIL, negative photoresists for standard UV lithography and PCB technology processing, and UV patterning of core and cladding.

This resin exhibits properties similar to quartz glass and is designed for ultra rigid, high aspect ratio nano and micro fabrication workflows.

Designed for nano and micro fabrication, UV lithography, PCB technology processing, Nano Imprinting Lithography NIL, spin coating, Reactive Ion Etching, wet and dry etching, and optical microfabrication workflows requiring ultra rigid high aspect ratio materials.

• Transparent ultra rigid stamp fabrication as an alternative to quartz or electroplated stamps
• Mass sensors based on UV-NIL, ALD and RIE
• Negative photoresists for standard UV lithography and PCB technology processing
• UV patterning of core and cladding

• Tensile strength: <40 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <40 MPa (ISO 178)
• Young’s modulus: 4000-6000 MPa (ISO 527)
• Elongation at break: <1% (ISO 527)
• Shore hardness: D90 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Water absorption: (ISO 20795-1)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Viscosity: optimized within the processing range required for the intended printing process and application
• Temperature resistance without deformation: up to 290 ºC (short term)
• Imprint temperature: >160ºC
• Printing resolution: less than 10 nm

• Heat deflection temperature: >290ºC (ISO 75)

• Refractive index: 1.45-1.55 (ISO 489)

• Resin with properties similar to quartz glass
• UV curable: excellent photoreactivity at 250-410 nm with minimum energy dosage
• Electron beam EB curable
• Compatible and blendable with our 3Dreyns for nano & micro fabrication
• Ultra rigid
• Durable
• High impact/shattering resistance
• High optical clarity
• High durability, non degradable
• Excellent bonding, low risk of debonding
• Medium-high mechanical properties, with low risk of cracking
• Very low degassing at high vacuum
• Ultra low oxygen sensitivity despite its ultra low viscosity
• High mechanical stability
• Ultra low penetration
• Low surface tension with good release and demolding properties
• 100% organic (free of inorganic materials)
• Optionally it can contain hydroxyl groups for bonding release agents, such as perfluorodecyltrichlorosilane (FDTS)

• Excellent balance of low viscosity for easy imprinting and low penetration
• Long shelf life of 1 year
• Excellent spin coating application
• Excellent etching with Reactive Ion Etching
• Excellent stability and chemical resistance to a wide range of wet chemistries used in the clean room
• No thermal treatment is required
• Easy processing with standard lithography equipment
• Easy removal of uncured resin with ketones, alcohols and esters

• UV & EB curable organic photopolymer
• Biocompatible
• Synthetic resin source
• Organo-tin free

Final imprinting behavior, lithography behavior, etching performance, optical properties, substrate compatibility and processing performance must be validated by the user according to the intended application and processing conditions.

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.

Access the 3Dresyns® Technical Resources (IFU, calibration, CRT, post-processing and troubleshooting)
