3Dresyn SA2 LV Bio, Biocompatible Flexibility and Softness Adjuster with low viscosity for detailed flexibility adjustment

3Dresyn SA2 LV Bio is our low viscosity biocompatible flexibility adjuster for detailed flexibility refinement of any of our 3Dresyns.

It is normally used up to 5-15% dosage, or more depending on printer and rigidity specifications for certain thickness, and it is used for adjusting the rigidity and hardness of any 3Dresyn with Shore below or above D40 to your personal choice.

Designed for use as a low viscosity flexibility adjuster in SLA, DLP and LCD vat photopolymerization workflows for detailed flexibility and rigidity refinement of compatible 3Dresyns.

• Detailed flexibility refinement of compatible 3Dresyns
• Adjusting rigidity and hardness of 3Dresyns with Shore below or above D40
• Custom flexibility adjustment of 3Dresyn formulations

• Tensile strength: <10 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <10 MPa (ISO 178)
• Young’s modulus: <10 MPa (ISO 527)
• Elongation at break: <70% (ISO 527)
• Notched Izod impact strength: 80-90 J/m (ASTM D256 / ISO 180)
• Shore hardness: D40 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Shrinkage: very low
• Appearance: clear, non yellowing

• Low viscosity refinement of printable 3D resins
• Viscosity: <20 mPas at 23°C ± 2°C (ISO 3219)

• Flexible and foldable without breaking
• Ideal for adjusting the rigidity and hardness of 3Dresyns with Shore below or above D40
• Medium hard and pliable
• High impact and shattering resistance
• Biocompatible
• Durable
• Very high resolution
• Hydrophobic

• Normally used up to 5-15% dosage, or more depending on printer and rigidity specifications for certain thickness
• Please do not expose any 3D resins to direct natural or artificial room light to prevent curing
• Increased durability of the resin tank
• Printable by most commercial and professional SLA, DLP & LCD 3D printers

• Synthetic resin source
• Organo-tin free
• Fully compliant with the Quality requirements of ISO 20795-1 and ISO 10993-1

Final flexibility refinement, rigidity adjustment, printability and mechanical performance depend on the base resin, additive dosage, printer, part thickness and full processing workflow, and must be validated by the user.

This material is supplied as a professional manufacturing additive and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
