3Dresyn VAM HDT1 Bio, Biocompatible high deflection temperature up to 290ºC resin printable by VAM 3D printers

3Dresyn VAM HDT1 Bio is a clear non colored liquid resin with high deflection temperature for VAM 3D printers.

This material is an ultra hard and rigid biocompatible photopolymer designed for durable high temperature applications and very high resolution printing workflows.

Designed for use in VAM 3D printers for fabrication of ultra hard and rigid parts, including durable molds for injection temperatures up to 290ºC.

• Durable molds for injection temperatures up to 290ºC
• Ultra hard and rigid printed parts
• High temperature VAM printing applications

• Tensile strength: <40 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <40 MPa (ISO 178)
• Young’s modulus: >5000 MPa (ISO 527)
• Elongation at break: <1% (ISO 527)
• Shore hardness: D90 (ISO 868)

• Density: 1.0-1.2 g/cc at 25ºC (ISO 1675)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Viscosity: <60.000 mPas at 23°C ± 2°C (ISO 3219)

• Heat deflection temperature: up to 290ºC @ 0.45 MPa (ISO 75)

• Refractive index: 1.50-1.52 (ISO 489)

• Ultra Hard and Rigid UHR
• High viscous non flowing resin at room temperature
• Durable
• Very high resolution

• Printable by VAM 3D printers
• Addition of a suitable photo accelerant and resolution-er system is required for printing in specific VAM printers


• Clear, non colored liquid resin
• Biocompatible
• Synthetic resin source
• Organo-tin free

High Heat Deflection Temperature HDT 3D resins despite being rigid tend to be fragile and have a short lifetime, degrading thermally at high temperature. If durable materials with high HDT are needed it is recommended the use of machined polyimide, or injecting PolyAmide Imide PAI or other high HDT conventional polymers in metal or 3D printed molds.

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
