3Dresyn VAM Soya2 Bio, bio based soya 3D resin for VAM 3D printers

3Dresyn VAM Soya2 Bio is a bio based and renewable photopolymer for VAM 3D printers.

Designed for use in VAM 3D printers for fabrication of hard, tough and rigid printed parts with certain flexibility, very high resolution and very low shrinkage.

• Plant-based VAM 3D printing applications
• Hard and tough printed parts with certain flexibility
• Eco friendly VAM printing workflows

• Tensile strength: <40 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <40 MPa (ISO 178)
• Young’s modulus: >1000 MPa (ISO 527)
• Elongation at break: <20% (ISO 527)
• Shore hardness: D50 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• VOCs: 0%
• Viscosity: <35.000 mPas at 23°C ± 2°C (ISO 3219)
• Renewable bio based content: >70%
• Layer curing speed: <3-5 seconds at 50 microns Z layers

• Bio based and renewable green source
• Eco-friendly, made from soybeans and plants
• Odour free
• Ultra fast curing
• Hard with certain flexibility
• Tough and rigid with certain flexibility
• Very high resolution

• Printable by VAM 3D printers
• Addition of a suitable photo accelerant and resolution-er system is required for printing in specific VAM printers


• Bio based and renewable source
• EN 71-3:2019 compliant
• BPA free
• Transition metals free

Final printability, curing speed, mechanical performance and suitability must be validated by the user according to the intended application, printer configuration and processing conditions.

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.
