3Dresyn VAM UTFD70 Bio, Biocompatible ultra tough & foldable resin with Shore D70 printable by VAM 3D printers

3Dresyn VAM UTFD70 Bio is an ultra tough and foldable biocompatible monomer free photopolymer for VAM 3D printers.

This material is designed to be foldable without breaking at low thickness and rigid with superior shattering resistance at medium and high thickness, providing properties similar to tough thermoplastics with Shore D70.

Designed for use in VAM 3D printers for fabrication of ultra tough, foldable and shatter resistant parts requiring very high resolution and very low shrinkage.

• Ultra tough and foldable printed parts
• Rigid parts with superior shattering resistance at medium and high thickness
• VAM printed parts with properties similar to tough thermoplastics with Shore D70 (ISO 868)

• Tensile strength: <30 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <30 MPa (ISO 178)
• Young’s modulus: <400 MPa (ISO 527)
• Elongation at break: <200% (ISO 527)
• Notched Izod: >90 J/m (ISO 180)
• Shore hardness: D70 (ISO 868)

• Density: 1.1-1.2 g/cc at 25ºC (ISO 1675)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Viscosity: <15.000 mPas at 23°C ± 2°C (ISO 3219)

• Refractive index: 1.47-1.49 (ISO 489)

• Ultra tough and foldable without breaking at low thickness
• Rigid with superior shattering resistance at medium and high thickness
• Non yellowing
• High impact and shattering resistance
• Properties similar to tough thermoplastics with Shore D70 (ISO 868)
• Durable
• Very high resolution

• Very high viscous non flowing resin at room temperature
• Printable by VAM 3D printers
• Addition of a suitable photo accelerant and resolution-er system is required for printing in specific VAM printers


• Monomer free
• Synthetic resin source
• Organo-tin free

Final foldability, shattering resistance, printability and mechanical performance must be validated by the user according to the intended application, thickness, printer configuration and processing conditions.

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.

Access the 3Dresyns® Technical Resources (IFU, calibration, CRT, post-processing and troubleshooting)
