4Dresyn E-LV1, Elastic Low Viscosity 4D resin

4Dresyn® E-LV1 is an elastic low viscosity 4D photopolymer designed to exhibit temperature-dependent mechanical behavior, transitioning from rigid below -5 °C to super elastic above 5 °C. It is intended to be combined with other 4Dresyn® materials to achieve customized 4D performance and programmed mechanical response.

Designed for use in SLA, DLP and LCD vat photopolymerization systems within controlled professional environments. Suitable for multi-material 4D printing applications requiring ultra-elastic response, extreme deformation capability and temperature-driven mechanical transitions.

• Ultra-elastic 4D printing systems with low-temperature activation
• Soft structures requiring extreme elongation and recovery
• Shape-morphing or adaptive components
• Flexible elements requiring high deformation capability
• Smart material prototypes with programmed elastic response

• Tensile strength: <2 MPa (ISO 527)
• Young’s modulus: <<2 MPa (ISO 527)
• Elongation: >>500% (ISO 527)
• Typical viscosity: <10 mPas at 23°C ± 2°C (ISO 3219)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Ultra-low viscosity resin enabling fast recoating and high detail resolution
• Ultra-low viscosity for excellent processability

• Thermal transition range: ~-5 to +5 °C

• Rigid behavior below -5 °C
• Super elastic behavior above 5 °C
• 100% foldability without breaking above transition temperature
• Designed for combination with other 4Dresyn® materials
• Extremely low viscosity for high processability
• Extreme elongation and deformation capability
• Durable performance under controlled conditions
• Very low shrinkage
• Synthetic resin source

• Designed for blending with more rigid 4Dresyn® systems to enable printability and tune mechanical response
• Compatible with SLA, DLP and LCD workflows when properly formulated in multi-material systems
• Suitable for advanced 4D material development applications

Material performance depends on printer type, exposure conditions, geometry, post-processing and multi-material formulation. Functional 4D behavior, elasticity and actuation must be validated by the user under the intended thermal and mechanical conditions.

• Ultra-elastic performance with extreme elongation (>>500%) (ISO 527)
• Low-temperature responsive rigid-to-elastic transition
• Designed for advanced multi-material 4D systems
• Very low shrinkage and high deformation capability
• Compatible with SLA, DLP and LCD workflows when combined
