4Dresyn R-LV1, Rigid Low Viscosity 4D resin

Product description

4Dresyn® R-LV1 is a rigid low viscosity 4D photopolymer designed to exhibit temperature-dependent mechanical behavior, transitioning from rigid below 100 °C to flexible above 120 °C. It is intended to be combined with other 4Dresyn® materials to achieve customized 4D performance and programmed mechanical response.

Application framework

Designed for use in SLA, DLP and LCD vat photopolymerization systems within controlled professional environments. Suitable for multi-material 4D printing applications requiring thermal actuation, shape adaptation or temperature-driven mechanical transitions.

Typical applications

• 4D printing systems requiring temperature-triggered mechanical change
• Multi-material assemblies with programmed stiffness variation
• Shape-morphing or adaptive components
• Thermally responsive structures
• Functional prototypes for smart material systems

Measured mechanical properties

• Thermal transition range: ~100–120 °C
• Tensile strength: <50 MPa (ISO 527)
• Flexural strength: <50 MPa (ISO 178)
• Shore hardness: D85–90 (ISO 868)
• Elongation: <3% (ISO 527)
• Typical viscosity: <15 mPa·s at 25 °C

Functional performance characteristics

• Rigid behavior below 100 °C
• Flexible behavior above 120 °C
• Designed for combination with other 4Dresyn® materials
• Extremely low viscosity for high processability
• Biocompatible-grade formulation with safe handling profile
• Durable performance under controlled conditions
• Very high resolution
• Low shrinkage
• Organo-tin free formulation
• Compatible with most SLA, DLP and LCD 3D printers
• Contributes to extended resin tank lifetime due to low viscosity

Processing and handling performance

• Ultra-low viscosity resin enabling fast recoating and high detail resolution
• Designed for blending with other 4Dresyn® systems to tune transition behavior
• Compatible with standard vat photopolymerization workflows
• Improved tank longevity compared to higher viscosity systems

Testing & processing disclaimer

Material performance depends on printer type, exposure conditions, geometry, post-processing and multi-material formulation. Functional 4D behavior must be validated by the user under the intended thermal and mechanical conditions.

Why choose 4Dresyn® R-LV1

• Temperature-responsive rigid-to-flexible transition
• Ultra-low viscosity for excellent printability
• Designed for customizable multi-material 4D systems
• High resolution and low shrinkage
• Compatible with standard SLA, DLP and LCD printers
• Durable and organo-tin free formulation
• Safe handling profile when properly processed

Regulatory & legal notice

This material is supplied as a professional manufacturing material and is not marketed as a finished product. Safe use requires appropriate personal protective equipment. Final performance, actuation behavior and application suitability remain the responsibility of the user.

Document reference: TDS-4DRESYN-R-LV1-EN | Version: 1.0 | Last updated: March 2026
