NextGen 3Dresyn TD80/TFD80 50/50 Tough Semi-Rigid Resin (D80)

NG 3Dresyn TD80/TFD80 50/50 is a hybrid photopolymer formulation designed to combine the toughness of NG 3Dresyn TD80 with the enhanced flexibility of NG 3Dresyn TFD80. The material provides a balanced mechanical profile, enabling parts that are resistant to fracture while allowing controlled deformation without breaking.

This formulation offers intermediate properties between rigid tough resins and flexible engineering materials, making it suitable for applications requiring both strength and flexibility.

Designed for use in vat photopolymerization systems (SLA, DLP and LCD) within professional and industrial environments for durable components requiring a balance between rigidity and flexibility.

• Functional parts requiring toughness and flexibility
• Snap-fit and living hinge components
• Impact-resistant housings and enclosures
• Engineering prototypes with balanced mechanical behavior

• Shore hardness: D80 (ISO 868)
• Mechanical properties: intermediate between NG 3Dresyn TD80 and NG 3Dresyn TFD80

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Resolution capability: very high (process-dependent)
• Color stability: non-settling formulation
• Viscosity: optimized within the processing range required for the intended printing process and application

• Tough (non-brittle) material behavior
• Minor flexibility without fracture
• High impact and shattering resistance
• Balanced rigidity and flexibility
• Durable under repeated mechanical stress

• Printing technologies: SLA, DLP and LCD
• Compatible with most commercial and professional systems when properly calibrated
• Stable processing and reliable printability

• Biocompatible (final part validation required)
• Synthetic resin base
• Organo-tin free formulation

Material properties are measured under controlled laboratory conditions and may vary depending on printer type, exposure conditions, layer thickness, build orientation and post-processing workflow.

This material is supplied as a professional manufacturing material for engineering and prototyping workflows. It is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.
