NextGen 3Dresyn TD90 Tough with Shore D90

Product description

NG 3Dresyn TD90 is a rigid and tough photopolymer formulation designed for engineering applications requiring a balance between high stiffness, strength and impact resistance. The material provides enhanced toughness compared to standard rigid resins, enabling improved resistance to cracking and shattering under mechanical stress.

This formulation is engineered to deliver durable, high-performance parts with good thermal stability and reliable mechanical behavior.

Application framework

Designed for use in vat photopolymerization systems (SLA, DLP and LCD) within professional and industrial environments for durable, rigid and impact-resistant components.

Typical applications

• Functional engineering components
• Impact-resistant housings and enclosures
• Structural prototypes requiring toughness
• Mechanical parts exposed to dynamic loads

Measured mechanical properties

• Tensile strength: >50 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: >80 MPa (ISO 178)
• Young’s modulus: 1500–3000 MPa (ISO 527)
• Elongation at break: <3–4% (ISO 527)
• Shore hardness: D90 (ISO 868)
• Notched Izod impact resistance: ~30–40 J/m (ISO 180)

Thermal properties

• Heat Deflection Temperature (HDT): >100–105°C @ 0.45 MPa

Measured physical properties

• Shrinkage: very low (typical)
• Resolution capability: very high (process-dependent)
• Color stability: non-settling formulation

Functional performance characteristics

• Rigid and tough material behavior
• Enhanced impact and shattering resistance
• High mechanical strength and durability
• Balanced stiffness and toughness
• Reliable performance under dynamic loading conditions

Processing and handling performance

• Printing technologies: SLA, DLP and LCD
• Compatible with most commercial and professional systems when properly calibrated
• Stable processing and consistent printability
• Increased durability of the resin tank during printing

Chemical and safety characteristics

• Biocompatible (final part validation required)
• Organo-tin free formulation

Testing & processing disclaimer

Material properties are measured under controlled laboratory conditions and may vary depending on printer type, exposure conditions, layer thickness, build orientation and post-processing workflow.

Disclaimer

This material is supplied as a professional manufacturing material for engineering and prototyping workflows. It is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

Document reference: TDS-NG-TD90-EN | Version: 1.0 | Last updated: March 2026
