3Dresyn OD-Clear CV1 MF Bio Ceramic Dental Coating Resin

3Dresyn® OD-Clear CV1 MF Bio is a monomer-free, ceramic-filled transparent dental coating formulation developed for professional laboratory surface finishing workflows of dental components requiring enhanced abrasion resistance, optical clarity and controlled surface performance.

The monomer-free formulation architecture is designed to support reduced residual monomer content when properly cured and post-processed, while maintaining transparent surface performance under validated laboratory conditions.

Designed for application within controlled professional laboratory environments on properly prepared dental substrates. Final suitability, validation and regulatory compliance of coated components must be assessed by the user according to the specific device design, workflow validation and applicable regulatory requirements.

• Professional laboratory surface finishing of dental components
• Transparent protective coating of dental substrates
• Dental components requiring enhanced abrasion resistance
• Dental components requiring optical clarity and controlled surface performance

• Tensile strength: > 50 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: > 90 MPa (ISO 178)
• Young’s modulus: 2500–3000 MPa (ISO 527-1 / ISO 527-2)
• Elongation at break: < 5 % (ISO 527)
• Shore hardness: D85–90 (ISO 868)

• Water sorption: ≤ 32 µg/mm³ (reference methodology aligned with ISO 20795-1)
• Water absorption: < 15 µg/mm³
• Water solubility: ≤ 1.6 µg/mm³ (reference methodology aligned with ISO 20795-1)

• High transparency and non-yellowing behavior
• Enhanced abrasion and wear resistance due to ceramic filler content
• Strong adhesion to properly prepared polymeric dental substrates under validated processing conditions
• Fast UV/visible light curing within 200–420 nm wavelength range
• Contains approximately 5% nano-ceramic fillers contributing to enhanced wear resistance and surface durability under validated curing conditions

• Transparent coating appearance
• High optical clarity
• Controlled surface performance for dental coating workflows
• Non-yellowing behavior

Surface performance, abrasion resistance and coating durability depend on validated substrate preparation, curing conditions and laboratory workflow.

• Monomer-free formulation
• Reduced residual monomer content when properly cured and post-processed
• Organo-tin free formulation

• Application type: professional laboratory coating workflow
• Curing wavelength range: 200–420 nm
• Application substrate: properly prepared dental substrates

• Biocompatibility-related evaluations may be conducted according to relevant ISO 10993 methodologies depending on formulation version and validated processing protocol
• Assessment and certification of any final medical device incorporating this coating remain the responsibility of the legal manufacturer

Material properties and coating performance may vary depending on substrate type, surface preparation, curing conditions and laboratory workflow validation. Reported information is provided for reference only.

• Monomer-free coating formulation
• Transparent coating with high optical clarity
• Enhanced abrasion and wear resistance from ceramic filler content
• Strong adhesion to properly prepared polymeric dental substrates
• Reduced yellowing with controlled surface performance

This material is supplied as a professional manufacturing material for laboratory workflows. It is not marketed as a finished medical device. The regulatory classification and compliance of any final dental device manufactured or coated using this material remain the sole responsibility of the legal manufacturer in accordance with applicable regulations, including Regulation (EU) 2017/745.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.

Access the 3Dresyns® Technical Resources (IFU, calibration, CRT, post-processing and troubleshooting)
