3Dresyn OD FDB Flexible Denture Base Resin

Product description

3Dresyn® OD FDB Flexible is a gingiva-colored flexible dental photopolymer formulation developed for professional laboratory fabrication workflows of flexible denture-base-type dental components requiring controlled elasticity, dimensional stability and mechanical durability.

Available in three natural gingiva-inspired shades. Final color outcome may vary depending on printing and post-processing parameters.

Application framework

Designed for use in vat photopolymerization systems (SLA, DLP and LCD) within controlled professional laboratory environments. Final suitability, validation and regulatory compliance of printed parts must be assessed by the user according to the specific device design, workflow validation and applicable regulatory requirements.

Typical applications

• Flexible denture-base-type dental components

Measured mechanical properties

• Tensile strength: <40 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <40 MPa (ISO 178 / ISO 20795-1 reference framework)
• Young’s modulus: 750–1250 MPa (ISO 527-1 / ISO 527-2)
• Elongation at break: <30% (ISO 527-1 / ISO 527-2)
• Shore hardness: D60–70 (ISO 868)
• Impact resistance (Notched Izod): <70 J/m (ISO 180)
• Stress relaxation: <10% after 1 week under controlled load (internal method)

Measured physical properties

• Water sorption (ULWA): ≤ 32 µg/mm³ (reference methodology aligned with ISO 20795-1)
• Water solubility: ≤ 1.6 µg/mm³ (reference methodology aligned with ISO 20795-1)
• Residual monomer content: reduced residual monomer content when properly cured and post-processed (internal method)
• Resolution capability: up to 20 microns
• Shrinkage: very low
• Viscosity of HV version: <8000 mPas at 23°C ± 2°C (ISO 3219)
• Viscosity of LV version: <4000 mPas at 23°C ± 2°C (ISO 3219)


Functional performance characteristics

• Controlled flexibility for denture-base-type components
• Elastic recovery behavior supported by shape-memory architecture
• Available in rigid and flexible versions depending on thickness and workflow requirements
• Mechanical behavior comparable to high-performance thermoplastic reference materials under controlled testing conditions
• Available in three natural gingiva-inspired shades

Processing and handling performance

• Designed for printing at 20–30°C
• LV and HV viscosity versions available depending on printer configuration
• Printable on most commercial and professional SLA, DLP and LCD 3D printers, including low room temperature environments
• Increased durability of the resin tank

Chemical and safety characteristics

• Organo-tin free formulation

Biocompatibility framework

• Biocompatibility-related evaluations may be conducted according to relevant ISO 10993 methodologies depending on formulation version and validated processing protocol
• Manufacturing aligned with ISO 13485 quality management systems
• Assessment and certification of any final medical device remain the responsibility of the legal manufacturer

Testing & processing disclaimer

Material properties are measured on printed and post-processed specimens and may vary depending on printer type, processing parameters, build orientation, post-curing conditions and workflow validation. Reported values are indicative and provided for reference only.

Disclaimer

This material is supplied as a professional manufacturing material for laboratory workflows. It is not marketed as a finished medical device. The regulatory classification and compliance of any final dental device manufactured using this material remain the sole responsibility of the legal manufacturer in accordance with applicable regulations, including Regulation (EU) 2017/745.

Document reference: TDS-OD-FDB-FLEXIBLE-EN | Version: 2.0 | Last updated: March 2026
