3Dresyn OD FRV Flexible Removable Veneer Resin (Vita Colors)

3Dresyn® OD FRV is a flexible colored dental photopolymer developed for professional laboratory fabrication workflows of aesthetic dental components and colored appliance elements.

The material combines controlled flexibility, dimensional stability and optimized optical performance for shade-matching applications.

It is available in multiple tooth-inspired shades and supports both rigid and flexible configurations depending on processing and workflow requirements.

Available shades: A1, A2, A3, A3.5, A4, B1, B2, B3, B4, C1, C2, C3, C4, D2, D3, D4 and BL1. Final shade appearance may vary depending on printing and post-processing conditions.

Designed for use in vat photopolymerization (SLA, DLP and LCD) systems within controlled professional laboratory environments.

Final suitability and regulatory compliance of printed parts must be validated by the user according to the specific device design, workflow validation and applicable regulatory requirements.

• Colored ligners and teeth movement systems
• Colored aesthetic dental appliance components
• Flexible veneer-type removable elements
• Colored orthodontic appliance components
• Flexible tray-type positioning elements
• Aesthetic dental mock-up components

• Tensile strength: <40 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <40 MPa (ISO 178 / ISO 20795-1)
• Young’s modulus: ~500–1000 MPa (ISO 527-1 / ISO 527-2)
• Elongation at break: <30% (ISO 527-1 / ISO 527-2)
• Impact resistance (Notched Izod): <70 J/m (ISO 180)
• Stress relaxation: <10% after 1 week under controlled load (internal method)
• Shore hardness: D60–70 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Water sorption (ULWA): ≤32 µg/mm³ (ISO 20795-1)
• Water solubility: ≤1.6 µg/mm³ (ISO 20795-1)
• Residual monomer: <0.1% when properly cured and post-processed (internal method)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Resolution capability: up to 20 µm
• Viscosity: mPas at 23°C ± 2°C (ISO 3219)
• Viscosity of HV version: <8000 mPas at 23°C ± 2°C (ISO 3219)

• Semirigid flexible behavior at low thickness (0.4–0.6 mm typical)
• Elastic recovery after deformation
• Memory behavior under moderate thermal activation
• High opacity in selected shades for masking effect
• Clear and non-yellowing base formulation
• Available in rigid and flexible performance configurations

• Printing technologies: SLA, DLP and LCD
• Wavelength range: 385–405 nm
• Designed for medium low temperature printing: 20–30 °C
• LV and HV viscosity versions available depending on printer configuration
• Very low shrinkage and high dimensional stability
• Printable on most commercial and professional systems
• Increased resin tank durability

• Organo-tin free formulation

• Biocompatibility-related testing may be performed according to ISO 10993 depending on formulation and validated workflow
• Material evaluation must be performed on the final printed and post-processed device
• Manufacturing aligned with ISO 13485 quality management systems

Material properties are measured on printed and post-processed specimens and may vary depending on printer type, processing parameters, build orientation, post-curing conditions and workflow validation. Reported values are indicative and provided for reference only.

This material is supplied as a professional manufacturing material for laboratory workflows. It is not marketed as a finished medical device. The regulatory classification and compliance of any final dental device manufactured using this material remain the sole responsibility of the legal manufacturer in accordance with applicable regulations, including Regulation (EU) 2017/745.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
