3Dresyn OD Try-In White Radiopaque – Radiopaque Dental Photopolymer for Professional Laboratory Workflows
Product description
3Dresyn® OD Try-In White Radiopaque is a rigid dental photopolymer designed for components requiring radiopacity, dimensional stability and structural accuracy.
Application framework
Designed for SLA, DLP and LCD systems for dental laboratory workflows. Radiopacity depends on imaging conditions and geometry.
Typical applications
- Dental try-in components
- Radiopaque dental models
- Imaging-visible validation parts
Measured mechanical properties
- Tensile strength: <50 MPa (ISO 527-1 / ISO 527-2)
- Flexural strength: <60 MPa (ISO 178)
- Young’s modulus: 2500–3000 MPa (ISO 527)
- Elongation at break: <3% (ISO 527)
- Shore hardness: D85–90 (ISO 868)
Measured physical properties
- Resolution capability: up to 20 µm
- Shrinkage: very low
- Viscosity: <4000 mPas at 23°C ± 2°C (ISO 3219)
Functional performance characteristics
- High rigidity and dimensional accuracy
- Radiopaque behavior under imaging conditions
- High resolution up to 20 µm
- Very low shrinkage
Processing and handling performance
- Printing technologies: SLA, DLP and LCD
- Compatible with most commercial systems
Chemical and safety characteristics
- Organo-tin free formulation
Biocompatibility framework
- Biocompatibility-related testing may follow ISO 10993 methodologies depending on formulation and validated workflow
- Final device validation remains the responsibility of the legal manufacturer
Testing & processing disclaimer
Material performance depends on processing conditions and post-curing parameters.
Disclaimer
This material is supplied as a professional laboratory material and is not marketed as a finished medical device. The regulatory classification and compliance of any final dental device manufactured using this material remain the sole responsibility of the legal manufacturer in accordance with applicable regulations.
This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
Document reference: TDS-OD-TRYIN-WHITE-EN | Version: 2.0 | Last updated: March 2026
