3Dresyn OD-Clear T&C Tough Night Guard & Splint Resin

3Dresyn® OD-Clear T&C is an advanced photopolymer engineered for the fabrication of dental protection appliances such as night guards and occlusal splints.

The material provides a balanced combination of toughness, comfort and controlled flexibility under load, enabling durable performance in cyclic mechanical environments.

The formulation is based on 4D Shape Memory Polymer (SMP) architecture, supporting shape recovery behaviour and stable mechanical response depending on geometry, thickness and processing conditions.

It is available in LV (lower viscosity) and HV (higher mechanical performance) versions for compatibility across SLA, DLP and LCD systems.

Intended for professional use in vat photopolymerization (SLA, DLP and LCD) additive manufacturing for dental laboratory workflows.

Final suitability of printed parts must be validated by the user according to the specific application, processing conditions and applicable regulatory requirements.

• Night guards and occlusal splints
• Dental protection appliances for bruxism and clenching
• Custom dental protective devices requiring resilience and comfort
• Flexible dental components and positioning elements

• Tensile strength: <40 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <40 MPa (ISO 178 / ISO 20795-2)
• Young’s modulus: ~600–1200 MPa (ISO 527-1 / ISO 527-2)
• Elongation at break: <30% (ISO 527-1 / ISO 527-2)
• Impact resistance (Notched Izod): <70 J/m (ISO 180)
• Shore hardness: D60–70 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Water sorption (ULWA): ≤32 µg/mm³ (ISO 20795-2)
• Water solubility: ≤1.6 µg/mm³ (ISO 20795-2)
• Residual monomer: <0.1% when properly cured and post-processed (ISO 20795-2)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Viscosity of HV version: <8000 mPas at 23°C ± 2°C (ISO 3219)

• Optical behaviour: excellent clarity and non-yellowing

• Controlled flexibility under load for improved comfort
• Shape recovery behaviour under cyclic stress
• Balanced stiffness for protection and wear resistance
• High durability under repeated mechanical loading
• 4D Shape Memory Polymer (SMP) architecture
• Shape memory activation via thermal stimulus
• Available in rigid and flexible performance configurations

• Printing technologies: SLA, DLP and LCD
• Wavelength range: 385–405 nm
• Compatible with open-parameter vat photopolymerization systems
• LV version optimized for printing below ~25 °C or without heated vats
• HV version optimized for printing above ~25 °C and enhanced mechanical performance
• Suitable for thin structures down to 0.2–0.3 mm
• Follow 3Dresyns IFU for exposure, washing and post-curing
• IFU for 100% clarity & transparency

• Organo-tin free formulation
• Ultra low water absorption (ULWA)

• Biocompatibility-related testing may be performed under controlled laboratory conditions depending on formulation and validated workflow
• Evaluation frameworks may include ISO 20795 and ISO 10993 methodologies
• Manufacturing aligned with ISO 13485 quality management systems
• Final biological performance depends on validated processing workflow

Material properties are measured on printed and post-processed specimens and may vary depending on material version, printer type, printing parameters, build orientation, post-curing conditions and workflow validation. Reported values are indicative and provided for reference only.

This material is supplied as a professional manufacturing material for dental laboratory workflows and is not marketed as a finished medical device. The regulatory classification, conformity assessment and validation of any final dental appliance manufactured using this material remain the sole responsibility of the legal manufacturer in accordance with applicable regulations, including Regulation (EU) 2017/745.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
