3Dputty SF-WS, our light curing Water Swellable sacrificial Soft & Flexible putty

Product description

3Dputty SF-WS is a light curing water swellable sacrificial soft & flexible putty curable with UV & visible light in seconds.

Its usage is ideal as water swellable sacrificial demolding filler for filling the gap between water soluble sacrificial 3D printed molds and injector flasks. Before exposure to UV / visible light it can be modelled by hand or with a spatula, and after shaping it can be hardened in seconds to become a water swellable sacrificial soft and flexible filler for easy demolding.

Application framework

Designed for sacrificial demolding workflows as a water swellable soft and flexible filler for filling gaps between water soluble sacrificial 3D printed molds and injector flasks, using UV & visible light curing.

Typical applications

• Water swellable sacrificial demolding filler
• Filling the gap between water soluble sacrificial 3D printed molds and injector flasks
• Easy demolding workflows
• Manual shaping and modelling before light curing

Measured mechanical properties

• Tensile strength: <1 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <1 MPa (ISO 178)
• Young’s modulus: MPa (ISO 527)
• Elongation at break: >90% (ISO 527)
• Shore hardness: A20 (ISO 868)

Measured physical properties

• Swelling: fast swelling in water


Functional performance characteristics

• Whitish non-sticky putty
• Soft, malleable, easy to shape with a spatula or by hand for easy application before curing
• Fast curing of even thick layers of several centimetres
• Sacrificial soft and flexible after light curing
• Synthetic resin source
• Long shelf life

Processing and handling performance

• Photocurable with UV & visible light
• Can be modelled by hand or with a spatula before curing
• Fast curing with normal UV / visible light in seconds
• Clean and postcure your 3D prints with Cleaning Fluid WS1 Bio

Chemical and safety characteristics

• Water swellable
• Synthetic resin source

Testing & processing disclaimer

Use gloves to prevent skin irritation and other hazards. Read the MSDS before handling it.

Disclaimer

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

Document reference: TDS-3DPUTTY-SF-WS-EN | Version: 1.0 | Last updated: March 2026
