3Dresyn 2PP HAR2 Bio, Biocompatible High Aspect Ratio ultra rigid photopolymer for two photon polymerization

3Dresyn 2PP HAR2 Bio is a biocompatible high aspect ratio ultra rigid photocurable resin with ultra high deflection temperature for two photon polymerization.

It is designed as a negative photoresist for high precision additive manufacturing of ultra rigid high aspect ratio 3D nano and microstructures, offering an excellent balance of resolution and writing speed.

Designed for two photon polymerization workflows, including Dip-in two-photon lithography DTPL / Dip-in Laser Lithography DiLL and conventional Two Photon Lithography TPL configurations, for fabrication of ultra rigid high aspect ratio nano and microstructures.

• High precision additive manufacturing of ultra rigid high aspect ratio 3D nano and microstructures
• Dip-in two-photon lithography DTPL / Dip-in Laser Lithography DiLL
• Conventional two photon polymerization systems / Two Photon Lithography TPL

• Tensile strength: <60 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: < 140 MPa (ISO 178)
• Young’s modulus: < 6000 MPa (ISO 527)
• Elongation at break: < 2% (ISO 527)
• Shore hardness: D90 ± 2 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Water absorption: <15 µg/mm3 (ISO 20795-1)
• Water solubility: ≤ 1,6 µg/mm3 (ISO 20795-1)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Optical transparency: 100% from 440 nm onwards into the Near Infrared NIR
• Viscosity, LV version: <1000 mPas at 23°C ± 2°C (ISO 3219)
• Viscosity, HV version: >2000 mPas at 23°C ± 2°C (ISO 3219)
• Achievable feature sizes: 100-200 nm

• Heat deflection temperature: <290ºC (ISO 75)

• Ideal 2PP biocompatible photocurable resin negative photoresist for high precision additive manufacturing of ultra rigid high aspect ratio 3D nano & microstructures with ultra high deflection temperature
• Excellent balance of resolution shape accuracy and writing speed
• Photoreactive from 200 to 410 nm with Fine Tuner 2PP FT8 Bio single 1 photon absorption
• Photoreactive from 600 to 810 nm with Fine Tuner 2PP FT8 Bio two photon absorption
• Ultra rigid
• Good adhesion on glass and other substrates
• Clear, non yellowing
• Durable

• Designed for Dip-in two-photon lithography DTPL also referred as Dip-in Laser Lithography DiLL where the 2PP resin is immersed upside down in the microscope objective
• Designed for conventional 2PP systems also refered as Two Photon Lithography TPL where the 2PP resin is positioned upright on the substrate
• Easy handling by direct drop casting
• Printable by most commercial two photon polymerization printers with wavelengths from 600 nm to 800 nm
• Supplied at different writing speeds: fast, intermediate, slow, and non reactive for custom control of writing speed and resolution
• Tunable with the free sampled Fine Tuner 2PP FT8 Bio for custom adjustment of writing speed
• Tunable with the free sampled Fine Tuner 2PP LB3 Bio for maximum resolution with submicron feature sizes
• Supplied in a relatively low and high viscosity version
• Choose a LV low viscosity version (<1000 mPas) for easy development or cleaning of uncured resin with conventional 2PP upright configurations
• Choose a HV high viscosity version (>2000 mPas) for upside down DiLL configurations
• Easy removal of uncured resin with conventional developers such as isopropanol IPA and propylene glycol methyl ether acetate PGMEA
• Ideally use our biocompatible Cleaning Fluid UNW1 Bio to preserve transparency, prevent whitening and chemical attack of IPA and conventional alcohols

• Biocompatible
• Synthetic
• Hydrophobic
• Organo-tin free

Final writing speed, resolution, feature size, adhesion, printability, transparency and cleaning performance depend on the selected version, printer configuration, wavelength, substrate, developer and full processing workflow. Performance must be validated by the user for each specific application.

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
