Cleaning Fluid UNW1 Bio – Ultra Non-Whitening Cleaner with Very Low Viscosity for Ultra Gloss and Transparency

Product description

Cleaning Fluid UNW1 Bio is a hydrophobic, bio-based cleaning fluid developed for washing and cleansing 3D printed photopolymer parts. It is specifically formulated to assist removal of unreacted resin, hydrophobic residues and surface byproducts.

UNW1 Bio is an Ultra Non-Whitening cleaning fluid with very low viscosity, designed for washing ultra-clear and ultra-transparent 3D prints while helping maintain gloss and optical clarity.

Application framework

Designed for washing and cleansing 3D printed photopolymer parts in advanced additive manufacturing workflows, including laboratory environments where high transparency and surface quality are required.

Typical applications

• Washing and cleansing 3D printed photopolymer parts
• Removal of unreacted resin, hydrophobic residues and surface byproducts
• Washing ultra-clear and ultra-transparent 3D prints while helping maintain gloss and optical clarity

Measured physical properties

• Viscosity: <10 mPas at 23°C ± 2°C (ISO 3219)

Functional performance characteristics

• Designed to minimize gloss reduction and whitening
• Helps preserve transparency of clear and transparent prints
• Effective resin removal for most 3Dresyns materials
• Low dosage required for effective cleaning

Processing and handling performance

• Suitable for washing and light post-curing by immersion at room temperature
• Suitable for immersion cleaning in glass or compatible plastic containers
• IFU for ultra gloss and transparency
• For an odorless medium-viscosity alternative, see Cleaning Fluid UNW2 Bio
• For cleaning water-soluble sacrificial resins, use Cleaning Fluid WS1 or Cleaning Fluid WS2 Bio.
• Used Cleaning Fluid may be regenerated by controlled light exposure (sunlight or curing unit).
• Residual uncured resin may polymerize into small solid particles, which can then be removed by filtration (e.g., paint filter).
• The filtered fluid may be reused for subsequent washing cycles, subject to quality verification by the user.

Chemical and safety characteristics

• Hydrophobic
• Bio-based

Testing & processing disclaimer

Performance depends on resin type, geometry and workflow validation. Users are responsible for verifying compatibility with their specific materials and applications.

Disclaimer

This product is a processing aid and not a medical device.

Document reference: TDS-CLEANING-FLUID-UNW1-BIO-EN | Version: 1.0 | Last updated: March 2026
