3Dresyn FA50 ESD, flexible, ESD compliant

This formulation is based on a monomer-based (MB) system engineered to provide soft, rubber-like behavior with excellent flexibility, requiring proper post-curing and cleaning to achieve final material performance.

• Soft grips, seals and cushioning elements
• Shock-absorbing and damping parts
• Wearable or contact components requiring high flexibility
• Engineering prototypes with rubber-like behavior

• Tensile strength: <10 MPa (ISO 527)
• Flexural strength: <5 MPa (ISO 178)
• Young’s modulus: <10 MPa (ISO 527)
• Elongation at break: >60% (ISO 527)
• Shore hardness: A50 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Resolution capability: very high (process-dependent)
• Viscosity: <50 mPas at 23°C ± 2°C (ISO 3219)
• Very low viscosity enabling easy processing and recoating
• Available colors: customizable

• Surface resistivity: <10⁹ ohms (IEC 61340-2-3)
• Compliant with ESD standards: EN 61340, EN ISO 20344–20347

• Highly flexible and rubber-like material behavior
• Foldable and deformable without breaking
• High impact and shattering resistance
• Excellent energy absorption and deformation recovery
• Durable under repeated flexing and compression
• Very high resolution with fine feature capability

• Printing technologies: SLA, DLP and LCD

• Compatible with most commercial and professional systems when properly calibrated
• Requires proper post-curing and cleaning to reach final performance and reduce residual reactivity

• Monomer-based (MB) formulation
• Proper post-curing and cleaning required
• Organo-tin free formulation

Material properties are measured under controlled laboratory conditions and may vary depending on printer type, exposure conditions, layer thickness, build orientation and post-processing workflow.

This material is supplied as a professional manufacturing material for engineering and prototyping workflows. It is not marketed as a finished product. Final part performance, safety and suitability must be validated by the user according to the intended application.
