3Dresyn UHV-UHTD90 Bio, Biocompatible ultra hard & tough resin with Shore D90 for Hot Lithograghy HL and Viscous Lithography Manufacturing VLM

Designed for use in Hot Lithography (HL) and Viscous Lithography Manufacturing (VLM) systems within controlled professional environments. Suitable for the fabrication of durable rigid parts, clear technical components, ophthalmic-related prototyping applications and molds requiring high toughness, dimensional stability and resistance to shattering.

• Durable molds for injection temperatures up to 100 °C
• Ultra-rigid and tough technical parts for HL and VLM workflows
• Clear non-yellowing components requiring optical stability
• Impact-resistant rigid parts with high hardness
• Ophthalmic lens-related prototyping and clear isotropic parts

• Tensile strength: >50 MPa (ISO 527)
• Flexural strength: 90–110 MPa (ISO 178)
• Flexural modulus: 2500–3000 MPa (ISO 178)
• Elongation: <3% (ISO 527)
• Shore hardness: D90 (ISO 868)
• Typical viscosity: <15,000 mPa·s at 20 °C (Brookfield)

• Density: 1.0–1.2 g/cc at 25 °C (ISO 1675)

• Heat deflection temperature (HDT): >100 °C (ISO 75)

• Refractive index: 1.47–1.49 (ISO 489)

• Ultra hard and tough (UHT) formulation for HL and VLM
• Ultra non-yellowing behavior
• High impact and shattering resistance
• Clear and isotropic appearance for demanding transparent parts
• Very high resolution
• Very low shrinkage
• Organo-tin free formulation
• Synthetic resin source

• Medium viscosity resin with medium flow at room temperature
• Compatible with Hot Lithography and Viscous Lithography Manufacturing systems
• Broader property adjustment can be achieved with 3Dresyn SA1 HV Bio and 3Dresyn HA1 HV MF Bio
• More detailed property adjustment can be achieved with 3Dresyn SA2 LV Bio and 3Dresyn HA2 LV Bio

Note: high hardness and high HDT photopolymers may still require application-specific validation depending on geometry, impact conditions, thermal exposure and long-term service environment. Optical performance for lens-related applications must be validated by the user under the intended manufacturing and post-processing conditions.

Material performance depends on printer type, thermal control, exposure conditions, geometry and full workflow implementation. Mechanical, optical and thermal performance must be validated by the user for each specific application.

• Ultra hard and tough performance for demanding rigid applications
• Clear, isotropic and ultra non-yellowing appearance
• Thermal resistance above 100 °C
• Suitable for HL and VLM manufacturing workflows
• Property tunable with dedicated adjusters

This material is supplied as a professional manufacturing material and is not marketed as a finished product. Final performance, optical suitability, durability and process validation remain the responsibility of the user depending on printer, part design, thermal exposure and workflow conditions.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
