3Dresyn UHV-UTFD70 Bio, Biocompatible Ultra Tough & Foldable resin with Shore D70 for Hot Lithograghy HL and Viscous Lithography Manufacturing VLM

Designed for use in Hot Lithography (HL) and Viscous Lithography Manufacturing (VLM) systems within controlled professional environments. Suitable for the fabrication of durable foldable parts, flexible components with high resilience and technical applications requiring toughness, controlled softness and very low shrinkage.

• Foldable technical parts requiring repeated deformation without breaking
• Soft-touch flexible components with high impact resistance
• Durable parts requiring high shattering resistance
• Flexible structural elements with controlled low hardness
• Applications requiring tunable rigidity while maintaining foldability

• Tensile strength: <30 MPa (ISO 527)
• Flexural strength: <30 MPa (ISO 178)
• Young’s modulus: <400 MPa (ISO 527)
• Elongation: <200% (ISO 527)
• Notched Izod impact strength: >90 J/m (ISO 180)
• Shore hardness: D70 (ISO 868)
• Typical viscosity: <12,000 cP at 70 °C; <6,000 cP at 80 °C; <3,000 cP at 90 °C; ~2,000 cP at 100 °C

• Density: 1.0–1.2 g/cc at 25 °C (ISO 1675)
• High viscosity, non-flowing resin at room temperature intended for heated HL and VLM workflows

• Refractive index: 1.47–1.49 (ISO 489)

• Ultra tough and foldable behavior without breaking
• Monomer-free, biocompatible-grade formulation
• Non-yellowing appearance
• High impact and shattering resistance
• Durable behavior under controlled processing conditions
• Very low shrinkage
• Organo-tin free formulation
• Synthetic resin source

• Compatible with Hot Lithography and Viscous Lithography Manufacturing systems
• Hardness and rigidity can be increased with 3Dresyn HA1 HV MF Bio at user-selected dosages typically in the range of 1–15% by weight, subject to validation
• Broader property adjustment can be achieved with 3Dresyn SA1 HV Bio and 3Dresyn HA1 HV MF Bio
• More detailed property adjustment without sacrificing foldability can be achieved with 3Dresyn SA2 LV Bio and 3Dresyn HA2 LV Bio

Note: highly flexible and foldable photopolymers may exhibit geometry-dependent mechanical behavior. Final flexibility, softness, foldability and durability depend on part thickness, curing conditions and thermal history and must be validated by the user for the intended application.

Material performance depends on printer type, thermal control, exposure conditions, geometry and full workflow implementation. Mechanical performance, foldability, softness and final suitability must be validated by the user for each specific application.

• Ultra tough and highly foldable performance for flexible applications
• Lower hardness (D70) for softer and more compliant parts
• Non-yellowing appearance and very low shrinkage
• Suitable for HL and VLM manufacturing workflows
• Rigidity tunable with dedicated adjusters

This material is supplied as a professional manufacturing material and is not marketed as a finished product. Final performance, durability, flexibility, foldability and process validation remain the responsibility of the user depending on printer, part design, thermal exposure and workflow conditions.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.

Access the 3Dresyns® Technical Resources (IFU, calibration, CRT, post-processing and troubleshooting)
