Professional 3D Printing System Architecture

Structured photopolymer system architecture for industrial, technical and regulated environments.

Minimum engagement: €20,000. These programs define complete additive manufacturing systems at material-process-hardware level. They are structured engineering implementation programs rather than basic troubleshooting or routine Product support.

Program level is determined by factors such as system complexity, required documentation, process-control depth, reproducibility requirements, intended application and project scope.

For applications in which material performance must also be specifically developed, System Architecture may be combined with Resin Customization Programs to address both material and process requirements under separately defined scopes.

Download TDS (PDF)

What System Architecture Covers

3Dresyns® Professional 3D Printing Architecture is intended to structure the interaction between the material, printer, exposure system, cleaning, post-processing, post-curing and application requirements.

Depending on the selected program and agreed project scope, work may include:

printer and hardware architecture;
exposure methodology;
curing strategy;
cleaning and post-processing workflow;
post-curing architecture;
material-process compatibility assessment;
parameter architecture;
process-window definition;
reproducibility methodology;
calibration methodology;
technical documentation structure; and
implementation guidance.

The specific activities and deliverables included are determined by the selected program and applicable quotation or project agreement.

Professional Architecture Program €20,000

This program is intended to establish a structured technical baseline for implementing or reorganizing a professional photopolymer workflow.

Complete photopolymer workflow architecture.
Hardware system definition, including printer, cleaning and post-curing requirements.
Exposure structuring methodology.
Parameter stabilization logic.
Structured written technical sessions.
Traceable implementation documentation within the agreed project scope.

Advanced Engineering Architecture €30,000

This program is intended for applications requiring deeper characterization of exposure, curing and process reproducibility than the Professional Architecture Program.

All Professional features.
Radiometric structuring and irradiance evaluation logic.
Working curve construction, including Dp and Ec extraction when required by the project.
CRT calibration alignment.
Mechanical validation framework, including SMSP integration where applicable.
Reproducibility control methodology.
Traceable parameter documentation framework.

Regulated Environment Architecture €45,000+

This program is intended for projects in which the customer requires an increased level of process traceability, documentation and technical justification because of the intended application or its own quality and regulatory framework.

All Advanced Engineering features.
Risk-based exposure design.
Biomedical, dental, packaging or food-contact structuring where applicable to the customer's intended application.
Controlled reproducibility alignment.
Extended validation-documentation logic.

Regulated Environment Architecture does not by itself constitute regulatory approval, certification or validation of the customer's final Product.

High-Risk / Class III / Pharmaceutical Architecture ≥ €150,000

This program is intended for high-complexity projects requiring extensive system-level engineering, documentation and risk-control architecture.

Full high-risk photopolymer system architecture.
Deep exposure validation and photopolymer modelling.
Regulatory-aligned documentation structuring where included in scope.
Advanced reproducibility and risk-control logic.
Fully customized project scope definition.

The name of this commercial program does not itself determine, certify or confirm the regulatory classification of the customer's final medical, pharmaceutical or other regulated Product.

High-Risk / Advanced Industrial System Architecture ≥ €150,000

This program is intended for technically demanding industrial systems where multiple material, hardware, process, documentation and implementation variables must be structured as an integrated architecture.

Full high-complexity photopolymer or additive manufacturing system architecture.
Advanced exposure validation, process modelling and reproducibility control.
Engineering, regulated, biomedical, pharmaceutical or mission-critical implementation logic where applicable to the agreed project.
Complex hardware, material, workflow and validation integration.
Regulatory-aligned or engineering-defensible documentation where required by the project scope.

System Architecture versus Troubleshooting

System Architecture is not intended to replace routine Product support or short troubleshooting engagements.

If an existing material and printing workflow fundamentally meet the application requirements but require parameter adjustment, failure analysis or process stabilization, Printing & Processing Consulting or Structured Additive Manufacturing Consulting may be more appropriate.

System Architecture is intended for projects requiring broader definition or restructuring of the complete material-process-hardware workflow.

System Architecture versus Resin Customization

System Architecture and Resin Customization are separate engineering programs.

System Architecture defines and structures how the additive manufacturing system should operate.

Resin Customization is used where the material itself must be developed or adapted because existing commercial materials do not meet the required technical target.

A System Architecture project does not automatically include custom formulation development.

Likewise, purchase of a Resin Customization project does not automatically include complete System Architecture.

Where both material and system development are required, the programs may be combined under an expressly defined project scope.

Material Architecture

System Architecture may involve selection, assessment and implementation of suitable 3Dresyns® material systems.

Recommendations concerning material selection or processing do not transfer the confidential formulation, chemical composition, synthesis route or proprietary manufacturing know-how underlying a 3Dresyns® Product.

If a new custom material must be developed, the work is governed separately under the applicable Resin Customization framework.

Hardware Architecture

Depending on scope, the program may consider hardware elements including:

printer technology and architecture;
light source and wavelength;
irradiance and exposure characteristics;
cleaning equipment;
post-curing equipment;
thermal or downstream processing equipment where relevant;
build configuration; and
other equipment affecting process implementation.

Hardware recommendations are made according to the technical requirements considered during the project and should not be interpreted as universal certification or endorsement of a particular third-party machine.

Exposure Architecture

Exposure methodology may be structured according to variables such as:

wavelength;
irradiance;
exposure time;
layer thickness;
material cure response;
printer architecture;
geometry;
working curve behaviour; and
required dimensional and mechanical performance.

Where included in scope, the project may use working-curve analysis, radiometric information, CRT methodology or other appropriate tools to establish the exposure framework.

Working Curves, Dp and Ec

Where technically relevant and included in the selected program, 3Dresyns® may structure working-curve analysis and determine or use parameters such as penetration depth (Dp) and critical exposure (Ec) for process-development purposes.

Values obtained under one equipment configuration or set of experimental conditions should not automatically be assumed to apply unchanged to every printer, light source, material version, geometry or processing environment.

CRT Calibration Alignment

Where applicable, Curing Rate Table or related calibration methodology may be integrated into the System Architecture to support structured adjustment of exposure and curing conditions.

Calibration information is intended to support establishment of an appropriate process window and does not constitute a guarantee that a single parameter set will produce identical results under all equipment or environmental conditions.

Mechanical Validation Framework

Where mechanical performance forms part of the project objective, the architecture may include a structured framework for evaluating relevant material and process variables.

Where applicable, this may include integration with 3Dresyns® SMSP methodology or other project-specific evaluation approaches.

The specific properties, test methods, conditions and acceptance criteria to be used should be defined according to the project requirements.

Reproducibility and Process Control

System Architecture may establish methods intended to improve process control and reproducibility by identifying relevant variables, acceptable operating windows and appropriate documentation.

Potential variables may include:

printer configuration;
exposure settings;
material version and lot;
temperature;
cleaning;
post-curing;
processing methodology;
part geometry and orientation;
equipment condition; and
operator-controlled process steps.

The purpose is to establish a technically structured process rather than to assume that equipment or material performance remains invariant under all operating conditions.

Technical Documentation

Depending on program level and agreed scope, System Architecture may include technical documentation such as:

workflow architecture;
recommended equipment configuration;
parameter-development logic;
process-control framework;
recommended operating windows;
risk-oriented technical considerations;
validation-documentation structure; and
implementation recommendations.

The exact documents supplied are defined by the applicable project scope.

Technical Targets versus Acceptance Criteria

Projects may be designed around technical objectives for printing performance, dimensional control, mechanical properties, reproducibility or other system-level requirements.

A technical objective does not automatically constitute a guaranteed contractual acceptance criterion.

Where a measurable result is intended to operate as an acceptance criterion, it should be expressly identified in the applicable project documentation together with the relevant conditions, test methodology and tolerance where appropriate.

Regulated and Performance-Critical Applications

System Architecture may be used to support customers developing workflows for biomedical, dental, food-contact, pharmaceutical-related, industrial or other performance-critical applications.

The architecture may take relevant technical, quality and documentation requirements into account where those requirements have been identified as part of the agreed project scope.

3Dresyns® does not determine the regulatory status or classification of the customer's final Product merely by supplying a System Architecture program.

The customer remains responsible for determining the regulatory pathway, classification, conformity-assessment requirements, testing, validation, registration and market authorization applicable to its final Product and intended use.

Class III and High-Risk References

References to Class III, high-risk, pharmaceutical or similar terminology in a program name identify the intended complexity and commercial scope of the applicable 3Dresyns® architecture program.

Such terminology should not be interpreted independently as a legal determination that the customer's final Product belongs to a particular regulatory class or that a particular regulatory pathway applies.

Regulatory classification depends on the final Product, its intended purpose, characteristics and the applicable jurisdiction and regulatory framework.

Customer Responsibilities

The customer is responsible for providing accurate information reasonably necessary to structure the project.

Depending on scope, this may include:

intended application;
printer manufacturer and model;
printing technology;
hardware configuration;
existing material;
current processing parameters;
cleaning and post-curing equipment;
target properties;
current failure modes;
production requirements;
quality requirements; and
known regulatory constraints.

Material project constraints that are not disclosed cannot reasonably be incorporated into the architecture.

Implementation and Validation

3Dresyns® provides the technical architecture and deliverables included in the agreed project.

The customer remains responsible for implementing and validating the resulting system within its actual manufacturing environment unless a specific implementation or validation activity has been expressly contracted.

Changes to printer hardware, material, material version, process parameters, equipment, geometry or downstream processing may require reassessment of previously established conditions.

Target Outcomes

Depending on the selected program, baseline and agreed scope, System Architecture may seek to:

improve process stability;
improve repeatability;
reduce uncontrolled parameter variation;
establish clearer processing windows;
structure material-hardware compatibility;
establish appropriate calibration methodology;
improve technical understanding of exposure behaviour;
improve traceability of processing conditions;
improve transfer from development to manufacturing; and
provide a more technically defensible implementation framework.

These are potential project objectives and not universal guaranteed outcomes.

No Guaranteed Regulatory or Commercial Outcome

Unless expressly established as a specific contractual deliverable, a System Architecture program does not guarantee:

regulatory approval;
a particular regulatory classification;
certification;
notified-body acceptance;
market authorization;
food-contact authorization;
pharmaceutical suitability or authorization;
commercial success;
patentability;
freedom to operate; or
identical performance under every printing or manufacturing condition.

Project Scope and Additional Work

The selected program establishes the commercial starting framework. The applicable quotation, order confirmation or project agreement defines the actual activities, deliverables, project assumptions and payment conditions.

Changes in application, hardware, target properties, regulatory requirements, materials, validation requirements or other material project variables may require additional work and a revised quotation.

Intellectual Property

System Architecture does not transfer ownership of 3Dresyns® formulations, material architectures, proprietary software, internal methodologies, trade secrets, development tools or other Background Intellectual Property.

The customer's pre-existing information, designs and Background Intellectual Property remain subject to the customer's applicable rights.

3Dresyns® does not acquire ownership of an independent customer invention merely because System Architecture services are provided.

Any project-specific ownership, licensing, patent or exclusivity arrangement must be expressly established in writing.

Confidentiality

Projects involving non-public technical information may be conducted under the applicable NDA or confidentiality framework.

3Dresyns® does not disclose confidential formulations, proprietary material architecture, internal development tools or other trade secrets as part of standard System Architecture work.

Customers should not disclose third-party Confidential Information unless they are authorized to provide it for the project.

No Customer Access to 3Dresyns® Facilities

Purchase of a Professional 3D Printing Architecture program does not grant the customer, its consultants, private auditors, notified bodies acting for the customer or other private third parties any right to access, inspect or audit 3Dresyns® facilities, laboratories, manufacturing areas, internal systems, development tools or confidential processes.

Project information and deliverables are exchanged through the methods established by 3Dresyns® and the applicable project framework.

Where expressly contracted, 3Dresyns® personnel may provide technical implementation support at the customer's facilities.

Communication and Project Delivery

Written technical communication is generally preferred to maintain technical clarity and traceability.

Depending on scope, projects may also include remote meetings, videoconferences, technical reports, data review and customer-site implementation support.

See the 3Dresyns Communication and Technical Support Policy.

Positioning

These programs are designed for organizations requiring structured, reproducible and technically defensible photopolymer or additive manufacturing implementation at system level.

If the primary constraint is material performance rather than system architecture, consider Resin Customization Programs.

If the existing material and system are fundamentally suitable but require troubleshooting or parameter optimization, consider Printing & Processing Consulting.

Governing Principle

3Dresyns® Professional 3D Printing Architecture defines structured material-process-hardware implementation frameworks according to the selected commercial program and agreed project scope. The service does not automatically include custom formulation development, regulatory approval or validation of the customer's final Product, does not transfer proprietary 3Dresyns® formulation architecture or Background Intellectual Property, and does not grant customers access to 3Dresyns® facilities or confidential systems.

Related Services and Policies
