3D-ADD NSA1, non stick additive for reducing the release force

3D-ADD NSA1 is an ultra effective Non Stick Additive for reducing the adhesion and release force of 3D resins on FEP or PDMS.

It reduces the adhesion of 3D resins on the FEP or PDMS of the resin tank (vat).

Designed for reducing the adhesion and release force of SLA, DLP & LCD 3D resins on FEP or PDMS in the resin tank (vat).

• Reducing adhesion of 3D resins on FEP or PDMS of the resin tank

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Viscosity: optimized within the processing range required for the intended printing process and application
• Recommended dosage: 3-5% or higher than 10% for very sticky resins
• Clear liquid lubricant

• Reduces tack or "stickiness" and adhesion of any 3D resins on the resin tank
• Reduces the release force needed to separate the prints from the surface of the vat during printing
• Reduces the risk of support breaking, print deformation and overall print failure
• Increases the durability of FEP and PDMS
• Improves the printability of difficult to print highly viscous and sticky 3D resins
• Does not affect the clarity nor the color of 3Dresins

• Excellent compatibility with SLA, DLP & LCD 3D resins
• Please do not expose any 3D resins to natural or room light to prevent their curing

• Biocompatible

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.

Access the 3Dresyns® Technical Resources (IFU, calibration, CRT, post-processing and troubleshooting)
