3Dresyn PC-like Polycarbonate Impact-Resistant Engineering Resin

3Dresyn® PC-like is a high-performance photopolymer engineered to replicate the mechanical behaviour of polycarbonate, offering high impact resistance, toughness and good stiffness. The material provides excellent optical clarity with minimal yellowing and incorporates bio-based content from renewable sources. Compared to conventional polycarbonate, it presents a lower glass transition temperature while maintaining strong mechanical performance. It is available in HV (higher mechanical performance) and LV (lower viscosity) versions for compatibility with SLA, DLP and LCD printing systems.

Intended for professional use in vat photopolymerization (SLA, DLP and LCD) additive manufacturing.
Final suitability of printed parts must be validated by the user according to the specific application, processing conditions and applicable regulatory requirements.

• Impact-resistant engineering components
• Transparent housings and protective covers
• Functional prototypes requiring toughness and clarity
• Mechanical parts under dynamic loading
• Biomedical and technical components requiring high toughness

• Tensile strength: <55 MPa (typical) (ISO 527-1 / ISO 527-2)
• Flexural strength (break): <55 MPa (typical) (ISO 178)
• Young’s modulus: 1000–1400 MPa (typical) (ISO 527-1 / ISO 527-2)
• Elongation at break: <40% (typical) (ISO 527-1 / ISO 527-2)
• Impact resistance (Notched Izod): >70 J/m (typical) (ISO 180)
• Shore hardness: D70 (ISO 868)

• Density: ~1.0–1.1 g/cm³ (typical) (ISO 1675)
• Water absorption: ultra low (ULWA, hydrophobic behaviour) (ISO 62)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Color: clear, non-yellowing unless color is added
• Bio-based content: >15% from renewable sources

• Glass transition temperature (Tg): >45 °C (typical) (ISO 11357-2)
• Note: lower than conventional polycarbonate (Tg ~147 °C)

• Excellent optical clarity with minimal yellowing

• Printing technologies: SLA, DLP and LCD
• Wavelength range: 385–405 nm
• Compatible with open-parameter vat photopolymerization systems
• LV (~<10,000 cP @ 25 °C): optimized for unheated printers or ambient temperatures below ~25 °C
• HV (~higher viscosity): optimized for heated systems and improved mechanical performance
• Follow 3Dresyns IFU for exposure, washing and post-curing to achieve target properties

• Biocompatible formulation platform
• Biocompatibility must be evaluated on the final printed and post-processed device according to ISO 10993
• Manufacturing aligned with ISO 13485 quality management systems
• Organo-tin free formulation

Material properties are measured on printed and post-processed specimens and may vary depending on the selected material version, printer type, printing parameters, build orientation, post-curing conditions and test specimen preparation. Reported values are indicative and provided for reference only.

• Polycarbonate-like high impact resistance and toughness
• Good stiffness with controlled flexibility
• Bio-based content from renewable sources
• Ultra low water absorption (ULWA) and hydrophobic behaviour
• Very low shrinkage and good dimensional stability
• Available in LV and HV versions for broader processing flexibility
• Open-system compatibility (385–405 nm) across SLA/DLP/LCD workflows

For polycarbonate-like 3D printing applications, compare other rigid engineering resin routes when the required balance shifts between impact resistance, optical clarity and low-friction behaviour.

• Engineering & Functional 3D Resins
• 3Dresyn PMMA-like
• 3Dresyn Acetal POM-like

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.

Access the 3Dresyns® Technical Resources (IFU, calibration, CRT, post-processing and troubleshooting)
