3Dresyn PMMA-like Acrylic High-Stiffness Transparent Engineering Resin

3Dresyn® PMMA-like is a high-performance photopolymer engineered to replicate and exceed the properties of polymethyl methacrylate (PMMA), combining high stiffness, optical clarity and improved toughness. The material provides transparent to light orange finishes depending on formulation, printing and post-curing conditions, while maintaining excellent dimensional stability and ultra low water absorption. It is available in HV (higher mechanical performance) and LV (lower viscosity) versions for compatibility with SLA, DLP and LCD printing systems.

Intended for professional use in vat photopolymerization (SLA, DLP and LCD) additive manufacturing.
Final suitability of printed parts must be validated by the user according to the specific application, processing conditions and applicable regulatory requirements.

• Transparent rigid engineering components
• Optical and light-transmitting parts
• High-stiffness housings and structural elements
• Medical and dental components requiring clarity and rigidity
• Functional prototypes requiring high dimensional stability

• Tensile strength: <40 MPa (typical) (ISO 527-1 / ISO 527-2)
• Flexural strength (break): 80–100 MPa (typical) (ISO 178)
• Young’s modulus: 2700–3300 MPa (typical) (ISO 527-1 / ISO 527-2)
• Elongation at break: <6% (typical) (ISO 527-1 / ISO 527-2)
• Impact resistance (Notched Izod): moderate to high (typical for toughened PMMA-like systems) (ISO 180)
• Shore hardness: D85–90 (ISO 868)

• Density: ~1.0–1.1 g/cm³ (typical) (ISO 1675)
• Water absorption: ultra low (ULWA, hydrophobic behaviour) (ISO 62)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Color: clear to light transparent orange depending on formulation and post-processing

• Glass transition temperature (Tg): >130 °C (typical) (ISO 11357-2)

• Optical behaviour: high clarity with controlled transparency
• Excellent optical clarity with controlled transparency

• Printing technologies: SLA, DLP and LCD
• Wavelength range: 385–405 nm
• Compatible with open-parameter vat photopolymerization systems
• LV (~lower viscosity): optimized for unheated printers or ambient temperatures below ~25 °C
• HV (~higher viscosity): optimized for heated systems and improved mechanical performance
• Follow 3Dresyns IFU for exposure, washing and post-curing to achieve target properties

• Biocompatible formulation platform
• Biocompatibility must be evaluated on the final printed and post-processed device according to ISO 10993
• Manufacturing aligned with ISO 13485 quality management systems
• Organo-tin free formulation

Material properties are measured on printed and post-processed specimens and may vary depending on the selected material version, printer type, printing parameters, build orientation, post-curing conditions and test specimen preparation. Reported values are indicative and provided for reference only.

• PMMA-like high stiffness with improved toughness
• High flexural strength (80–100 MPa) (ISO 178)
• High thermal resistance (Tg >130 °C)
• Ultra low water absorption (ULWA) and hydrophobic behaviour
• Very low shrinkage and excellent dimensional stability
• Available in LV and HV versions for broader processing flexibility
• Open-system compatibility (385–405 nm) across SLA/DLP/LCD workflows

For PMMA-like 3D printing applications and transparent rigid parts, compare other engineering resin routes when the priority shifts between optical clarity, low-friction behaviour and impact resistance.

• Engineering & Functional 3D Resins
• 3Dresyn PC-like
• 3Dresyn Acetal POM-like

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.

Access the 3Dresyns® Technical Resources (IFU, calibration, CRT, post-processing and troubleshooting)
