3Dresyn ABS-like Acrylonitrile Butadiene Styrene Engineering Resin

3Dresyn® ABS-like is a high-performance engineering photopolymer designed to replicate the balanced mechanical behaviour of ABS thermoplastics. It combines rigidity with controlled flexibility and impact resistance, enabling the production of durable and functional parts.

The material is available in HV (higher mechanical performance) and LV (lower viscosity) versions to ensure compatibility across a wide range of SLA, DLP and LCD systems.

Designed for functional engineering and technical applications requiring toughness, dimensional stability and reliable mechanical performance.

• Functional engineering components and enclosures
• Durable housings, clips and snap-fit parts
• Jigs, fixtures and tooling elements
• Impact-resistant prototypes
• Biomedical and technical components requiring balanced stiffness and toughness

• Tensile strength: <50 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <80 MPa (ISO 178)
• Young’s modulus: 1000-2000 MPa (ISO 527)
• Elongation at break: <10% (ISO 527)
• Impact resistance: Notched Izod <40 J/m (ISO 180)
• Shore hardness: D70–80 (ISO 868)

• Density: 1.0–1.1 g/cm³ (ISO 1675)
• Water absorption: ultra low (hydrophobic behaviour) (ISO 62)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Appearance: clear with slight yellowing unless pigmented

• Glass transition temperature (Tg): >60 °C (ISO 11357-2)

• ABS-like balance between rigidity and flexibility
• High impact resistance and toughness
• Good dimensional stability with low shrinkage
• Hydrophobic behaviour with very low water uptake
• Reliable performance under mechanical stress

• Printing technologies: SLA, DLP and LCD
• Wavelength range: 385–405 nm
• HV version: optimized for maximum mechanical performance
• LV version: optimized for improved flow and ease of processing
• Compatible with open-parameter systems
• Optimized using 3Dresyns IFU and calibration workflow

• Biocompatible formulation platform
• Final device must be validated according to ISO 10993
• Manufacturing aligned with ISO 13485

Material properties are measured under controlled laboratory conditions and may vary depending on printer type, exposure conditions, layer thickness, build orientation and post-processing workflow.

This material is supplied as a professional engineering material. Final part performance and suitability must be validated by the user according to the intended application and regulatory requirements.
