3Dresyn TFD70 ESD, tough and foldable, ESD compliant

This formulation is engineered to provide non-brittle behavior, allowing parts to flex and deform without breaking while maintaining excellent printability and surface resolution.

• Protective housings and snap-fit parts
• Electronics handling tools
• Impact-resistant functional parts
• Engineering prototypes requiring flexibility and durability

• Tensile strength: <20 MPa (ISO 527)
• Flexural strength: <25 MPa (ISO 178)
• Young’s modulus: <500 MPa (ISO 527)
• Elongation at break: <40% (ISO 527)
• Shore hardness: D70 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Resolution capability: very high (process-dependent)
• Viscosity: optimized within the processing range required for the intended printing process and application
• Available colors: customizable

• Surface resistivity: <10⁹ ohms (IEC 61340-2-3)
• Compliant with ESD standards: EN 61340, EN ISO 20344–20347

• Tough, non-brittle and flexible material behavior
• Can be bent or folded without breaking
• High impact and shattering resistance
• Medium rigidity with controlled flexibility
• High dimensional stability
• Durable under repeated deformation
• Very high resolution with fine feature capability

• Printing technologies: SLA, DLP and LCD

• Compatible with most commercial and professional systems when properly calibrated
• Stable processing behavior across a wide range of conditions

• Biocompatible (final part validation required)
• Synthetic resin base
• Organo-tin free formulation

Material properties are measured under controlled laboratory conditions and may vary depending on printer type, exposure conditions, layer thickness, build orientation and post-processing workflow.

This material is supplied as a professional manufacturing material for engineering and prototyping workflows. It is not marketed as a finished product. Final part performance and suitability must be validated by the user according to the intended application.
