Thinner 3Dresyn E, elastic reactive diluent

Thinner 3Dresyn E is an elastic reactive diluent with low deflection temperature.

Thinner 3Dresyn E has extremely low viscosity and excellent viscosity reduction while imparting elasticity and 100% foldability without breaking in compatible 3D resin systems.

Designed for use as an elastic reactive diluent in compatible SLA, DLP & LCD 3D resin systems, once combined with more rigid resins.

• Reducing viscosity of compatible 3D resin systems
• Formulating elastic 3D resin systems once combined with more rigid resins

• Tensile strength: <2 MPa (ISO 527-1 / ISO 527-2)
• Young’s modulus: <<2 MPa (ISO 527)
• Elongation at break: >>500% (ISO 527)
• Shore hardness: O50 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Viscosity: <10 mPas at 23°C ± 2°C (ISO 3219)
• Low deflection temperature (ISO 75)
• Very low shrinkage

• Imparts elasticity and 100% foldability without breaking
• Durable

• Printable by most commercial and professional SLA, DLP & LCD 3D printers once combined with more rigid resins

• Synthetic resin source
• Avoid always contact with skin and eyes by using gloves and goggles

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.
