3D-POWDER SLS NYLON11 15-85, fine & narrow particle size distribution polyamide 11 (Nylon 11) powder for high resolution SLS printing

3D-POWDER SLS NYLON11 15-85 is a specifically designed fine and narrow particle size distribution polyamide 11 (Nylon 11) powder for SLS printing of high accuracy and resolution nylon printed parts.

This white thermoplastic SLS powder is designed for direct SLS printing of high quality Nylon 11 parts, with very high toughness and mechanical strength.

Designed for selective laser sintering of polymer powder parts requiring high accuracy, high resolution, toughness and mechanical strength. Also suitable as an additive for Cold Metal Fusion, Cold Ceramic Fusion, Cold Polymer Fusion and Cold Exotic Powder Materials Fusion workflows.

• Direct SLS printing of high quality Nylon 11 parts
• High accuracy and high resolution SLS printed parts
• Cold Metal Fusion, Cold Ceramic Fusion, Cold Polymer Fusion and Cold Exotic Powder Materials Fusion with 10% addition for improved and faster debinding

• Tensile strength: 45-50 MPa (ISO 527-2)
• Flexural strength: 45-50 MPa (ISO 178)
• Young’s modulus: 1700-1900 MPa (ISO 527-2)
• Flexural modulus: 1200 MPa (ISO 178)
• Elongation at break: 40-50% (ISO 527-2)
• Izod impact strength, notched: 100 J/m (ASTM D256 & ISO 180)
• Shore hardness: D75-80 (ISO 868)

• Density: 1.04 g/cm³ (ISO 1183-1)
• Water absorption after 24 hours: <1% (ISO 62)
• Coefficient of Friction COF-static: 0.3 (ISO 8295)
• High accuracy and resolution of final products: 50-100 microns depending on laser spot size and layer thickness

• Heat Deflection Temperature HDT at 1.8 MPa: 45-50ºC (ISO 75)
• Vicat softening temperature: 175-185ºC (ISO 306/B50)
• Melting temperature: 180-190ºC (ISO 11357-3)
• Service temperature: from -40ºC up to 100ºC continuous / +150ºC short term

• Ideal SLS powder for direct SLS printing of high quality Nylon 11 parts
• White thermoplastic SLS powder with very high toughness and mechanical strength
• Printable by most plastic / polymer powder SLS printers
• Similar properties and printing settings to Formlabs Nylon 11, EOS PA 1101, and Rolaserit PA11 (AM Polymers)
• Bio-based
• Excellent flow and levelling

• Typical narrow particle size distribution in microns, not to be considered a specification:
• D100: 140 (100% of particles have less than 140 microns)
• D90: 85 (90% of particles have less than 85 microns)
• D50: 43 (50% of particles have less than 43 microns)
• D10: 15 (10% of particles have less than 15 microns)
• D1: 3 (1% of particles have less than 3 microns)
• Recommended plastic or polymer powder SLS printers: SLS printer compatibility
• Suitable for FORMIGA P 110 Velocis, EOS P 396, and EOS P 770
• Recommended printing process: use the standard printing parameters of your equivalent polymer powder and follow 3Dresyns IFU for SLS printing
• For Cold Metal Fusion, Cold Ceramic Fusion, Cold Polymer Fusion, and Cold Exotic Powder Materials Fusion, add 10% of 3D-POWDER SLS NYLON11 15-85 for improved and faster debinding
• For more information read About Cold Metal Fusion CMF, Cold Ceramic Fusion CCF, and Cold Exotic Powders Fusion CEPF
• Additional related resource: Powder Binders for SLS Cold Metal, Ceramic & Exotic Powder Fusion

• Polyamide 11 (Nylon 11)

The reported properties may vary depending of part design and manufacturing practices. It is the manufacturer’s responsibility to adjust the printing parameters and validate the suitability of the printed parts for the intended use. 3Dresyns makes no guarantee of properties, expressed or implied, regarding the accuracy of these results to be obtained from the use thereof.

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.
