3Dresyn TD90 ESD, Rigid & Tough, ESD compliant

This formulation is based on a synthetic resin system engineered to provide a balanced combination of stiffness, toughness and durability while maintaining excellent printability and surface resolution.

• Electronics manufacturing components
• Protective housings and enclosures
• Structural parts requiring high strength and toughness
• Functional prototypes with ESD control

• Tensile strength: >50 MPa (ISO 527)
• Flexural strength: >100 MPa (ISO 178)
• Young’s modulus: 2000–3000 MPa (ISO 527)
• Elongation at break: <3% (ISO 527)
• Impact resistance (Notched Izod): 20–30 J/m (ISO 180)
• Shore hardness: D90 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Water absorption (ULWA): ≤ 32 µg/mm³ (ISO 62)
• Water solubility: ≤ 1.6 µg/mm³
• Printing shrinkage: no measurable dimensional shrinkage after calibration under validated processing conditions
• Resolution capability: very high (process-dependent)
• Color stability: non-settling formulation
• Viscosity: <8000 mPas at 23°C ± 2°C (ISO 3219)

• Heat Deflection Temperature (HDT): >100–105°C @ 0.45 MPa (ISO 75)

• Surface resistivity: <10⁹ ohms (IEC 61340-2-3)
• Compliant with ESD standards: EN 61340, EN ISO 20344–20347

• Extra hard material with balanced toughness
• High mechanical strength and stiffness
• Enhanced impact and shattering resistance
• Hydrophobic behavior with ultra low water absorption (ULWA)
• High dimensional stability
• Durable under functional loading conditions
• Very high resolution with fine feature capability

• Printing technologies: SLA, DLP and LCD

• Compatible with most commercial and professional systems when properly calibrated
• Stable processing behavior across a wide range of conditions
• Increased durability of the resin tank during printing

• Biocompatible (final part validation required)
• Synthetic resin base
• Organo-tin free formulation

Material properties are measured under controlled laboratory conditions and may vary depending on printer type, exposure conditions, layer thickness, build orientation and post-processing workflow.

This material is supplied as a professional manufacturing material for engineering and prototyping workflows. It is not marketed as a finished product. Final part performance and suitability must be validated by the user according to the intended application.
