3Dresyn HP1 BTO70 High Permittivity resin with ferroelectric, pyroelectric, and piezoelectric properties

3Dresyn® HP1 BTO70 is a high-permittivity photopolymer formulation based on Barium Titanate (BTO), engineered for advanced dielectric and functional electronic applications. The material is supplied as a free-flowing paste containing high dielectric ceramic loading, enabling the fabrication of components with elevated relative permittivity using SLA, DLP and LCD 3D printing workflows.

This formulation enables the design and manufacturing of functional dielectric devices with controlled electrical behavior across RF and microwave frequency ranges.

Designed for use in advanced additive manufacturing systems (SLA, DLP and LCD) within research, electronics and high-frequency engineering environments requiring controlled dielectric properties.

• High permittivity dielectric components
• RF and microwave devices
• Antennas and resonators
• Filters and RF cavities
• Sensors and transducers
• Capacitors, resistors and insulating components
• Functional electronic and electromagnetic devices

• Elongation at break: <5% (ISO 527)

• Relative permittivity (ε_r): 8–9 (typical) (IEC 62631-2-1)
• Loss tangent (δ): <0.04 at 10–20 GHz

• High dielectric constant for advanced electromagnetic design
• Suitable for high-frequency applications (RF and microwave)
• Stable dielectric performance across relevant frequency ranges
• Enables miniaturization of electronic components
• Compatible with multi-material and hybrid manufacturing approaches

• Based on Barium Titanate (BTO) high dielectric ceramic system
• Ferroelectric, pyroelectric and piezoelectric behavior
• Free-flowing paste formulation
• Medium hardness material behavior

• Printable with professional SLA, DLP and LCD systems
• High resolution capability depending on process parameters
• Very low shrinkage during processing
• Optimized for stable layer formation and repeatability
• Alternative processing route: injectable catalysed system in sacrificial or durable 3D printed molds

Dielectric performance is dependent on printing parameters, geometry, frequency range and post-processing conditions. Calibration and validation are required for each specific application.

• Inorganic-organic hybrid system (ceramic-filled photopolymer)
• Free of toxic heavy metals
• Read the MSDS before use and handle according to standard laboratory practice

Electrical and mechanical properties are measured under controlled conditions and may vary depending on printer type, exposure parameters, geometry and post-processing workflow.

This material is supplied as a professional functional material for research and engineering workflows. It is not marketed as a finished electronic device. Final performance and suitability must be validated by the user.
