3Dresyn IJ OD FRV for printing flexible removable veneers and colored aligners in A1, A2, A3, A3.5, A4, B1, B2, B3, B4, C1, C2, C3, C4, D2, D3, D4 & Bleach BL1 tooth colors has these features and benefits:
- ideal for printing colored veneers
- ideal for printing colored aligners for aesthetics
- colored aligners can be used for hiding missing or ugly teeth temporarily during treatment
- printable with most commercial and professional Inkjet 3D printers
- Stratasys: Objet Eden 260V, 260VS, 333, 350, 350V, 500, 500V, 1000 Plus, J750, Objet Connex 260, 350 and 500 series
- 3D Systems: ProJet MJP 2500, 2500+, 3500, 3510 and 3600 Plastic series
- ideal for printing ultra safe flexible removable veneers and colored aligners at 0.4-0.6 mm thickness with similar properties to PETG without damaging the periodontal ligament
- opaque A1, A2, A3, A3.5, A4, B1, B2, B3, B4, C1, C2, C3, C4, D2, D3, D4 & Bleach BL1 tooth colors for maximum hiding of teeth
- ideal for the direct printing of teeth movement aligners without damaging the periodontal ligament
- tough and foldable , semirigid, pliable under pressure at low thickness, with good memory until regains its original shape
- based on 4D Shape Memory Polymers SMP´s, with excellent shape memory with temperature, recovering their shape upon heating
- safe and biocompatible: only mild skin irritant before curing and cleansing
- available in two versions: rigid and flexible versions for printing aligners
- rigid version: similar properties to PETG disk
- rigid version: ideal for 0.5-0.8 mm
- flexible version: similar properties to TPU disk
- flexible version: ideal for 0.6-0.9 mm
- suitable for printing flexible thin copings or Indirect Bonding Trays IBTs at 0.2-0.3 mm for placing attachments
- Shore hardness D60-70 range
- <10% stress relaxation after 1 week at 2, 10 and 20 MPa initial stress
- excellent clarity and non yellowing
- flexural strength >40 MPa and up to 80 MPa with the optimum printing and postcuring process
- elongation <30%
- high impact and shattering resistance (Notched Izod <70 J/m)
- tensile strength >40 MPa
- rigid and flexible versions with medium rigidity (Young modulus 1000-1800 MPa)
- rigid version closer to 1800 MPa for thickness <0.6 mm
- flexible version closer to 1000 MPa for thickness > 0.6 mm
- durable, non yellowing
- high resolution up to 20 micron
- very low shrinkage
- organo tin free
- increased durability of the resin tank
- water solubility: ≤ 1,6 µg/mm3
- hydrophobic, ultra low water sorption ULWA≤ 32 µg/mm3
- residual monomer <0.1%
- fully compliant with the Quality requirements of FDA, ISO 20795, 13485 & 10993
- Watch pictures and videos of aligners printed with our resins: Pictures & videos for dentistry
- wash and clean aligners with Cleaning Fluid NW1 Bio for maximum clarity & transparency
-
IFU for 100% clarity & transparency (without any haziness or whitish finishing)
Note: Disclaimer for printing aligners
Our 3Dresyns for printing flexible removable veneers and colored aligners are made of bioplastics and are more ecological and biodegradable than the existing materials used for making aligners (models and conventional thermoformed plastic disks), which use non biodegradable petroleum based plastics.
Our 3Dresyns for printing removable veneers and colored aligners are made of bioplastics and are more ecological and biodegradable than the existing materials used for making removable veneers, which use non biodegradable petroleum based plastics.
