3Dresyn IM-UHT-WS High-Strength Rigid Water-Soluble Sacrificial Resin

3Dresyn® IM-UHT-WS is a high-strength rigid water-soluble sacrificial mold-making photopolymer developed for SLA, DLP and LCD mold-making workflows requiring dimensional stability, high mechanical resistance and thermal resistance during injection or casting.

Designed for use in vat photopolymerization systems (SLA, DLP and LCD) within controlled professional environments. Suitable for the fabrication of water-soluble sacrificial molds requiring a high-strength rigid D90 profile with thermal resistance during injection and casting workflows.

• High-temperature injection molds
• Molds for ceramic injection molding (CIM)
• Molds for metal injection molding (MIM)
• Thermal-resistant sacrificial tooling

• Tensile strength: <55 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <55 MPa (ISO 178)
• Young’s modulus: <4000 MPa (ISO 527)
• Elongation at break: <2% (ISO 527)
• Shore hardness: D90 (ISO 868)

• Density: 0.90–1.20 g/cm³, depending on formulation and, where applicable, selected version (ISO 1675)
• Water solubility
• Viscosity: <100 mPas at 23°C ± 2°C (ISO 3219)
• Very low shrinkage

• Heat deflection temperature (HDT): <120 °C @ 0.45 MPa (ISO 75)


• High mechanical strength and rigidity (high-strength rigid D90 profile)
• Thermal resistance during injection and casting workflows
• Water solubility for post-process mold removal

• Printable by SLA, DLP and LCD
• Cyan version is recommended for increased dimensional accuracy vs clear version
• Stable under high temperature injection conditions
• Recommended printing temperature: 20–25 °C

• Metal-free
• Organo-tin free

Thermal performance depends on post-curing conditions. Validation required per application.

This material is supplied as a professional manufacturing material and is not marketed as a finished product.
