3Dresyn RIC-HDT1 Bio, Biocompatible high deflection temperature up to 290ºC resin for Resin Injection and Casting

3Dresyn RIC-HDT1 Bio is a clear non colored liquid resin for Resin Injection and Casting.

This material is an ultra hard and rigid biocompatible formulation designed for durable high temperature mold making, casting and injection workflows, with high heat deflection temperature and very high rigidity.

Designed for Resin Injection and Casting workflows, including hot gravity casting, injection in molds, and fabrication of durable molds for injection temperatures up to 290ºC.

• Durable molds for injection temperatures up to 290ºC
• Resin Injection and Casting workflows
• Hot gravity casting in molds
• Injection casting in molds

• Tensile strength: <40 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <40 MPa (ISO 178)
• Young’s modulus: >5000 MPa (ISO 527)
• Elongation at break: <1% (ISO 527)
• Shore hardness: D90 (ISO 868)

• Density: 1.0-1.2 g/cc at 25ºC (ISO 1675)
• Shrinkage: very low
• Viscosity: <60.000 mPas at 23°C ± 2°C (ISO 3219)

• Heat deflection temperature: up to 290C @0.45MPa (ISO 75)

• Refractive index: 1.50-1.52 (ISO 489)

• Ultra Hard and Rigid (UHR)
• High viscous non flowing resin at room temperature
• Durable
• Very high resolution

• Castable hot by gravity or by injection in molds
• Hardness and rigidity can be custom increased with our Hardness Adjuster 3Dresyn HA1 HV MF Bio at your optimum dosage of 1-15% by weight
• Significant rigidity refinement can be done with our Hardness Adjusters 3Dresyn SA1 HV Bio and 3Dresyn HA1 HV MF Bio
• Detailed rigidity refinement without sacrificing foldability can be done with our Hardness Adjusters 3Dresyn SA2 LV Bio and 3Dresyn HA2 LV Bio
• Curable with light with Fine Tuners FT additives photo accelerants
• Curable by heat with Fine Tuner TA1, our general purpose fast thermal accelerant for thermally curing our 3Dresyns

• Clear, non colored liquid resin
• Biocompatible
• Synthetic resin source
• Organo-tin free

High Heat Deflection Temperature HDT 3D resins despite being rigid tend to be fragile and have a short lifetime, degrading thermally at high temperature. If durable materials with high HDT are needed it is recommended the use of machined polyimide, or injecting PolyAmide Imide PAI or other high HDT conventional polymers in metal or 3D printed molds.

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.

Access the 3Dresyns® Technical Resources (IFU, calibration, CRT, post-processing and troubleshooting)
