3Dresyn RIC-TFD60 Bio, Biocompatible Tough & Foldable resin with Shore D60 for Resin Injection and Casting

3Dresyn RIC-TFD60 Bio is a tough and foldable resin for injection and casting.

This material is designed to be tough and foldable without breaking, while maintaining high impact and shattering resistance, very low shrinkage and non yellowing performance for resin injection and casting workflows.

Designed for resin injection and casting workflows, including hot gravity casting and injection in molds, for fabrication of tough and foldable parts.

• Tough and foldable resin injection and casting
• Hot gravity casting in molds
• Injection casting in molds
• Tough and foldable cast parts

• Tensile strength: <20 MPa (ISO 527-1 / ISO 527-2)
• Flexural strength: <20 MPa (ISO 178)
• Young’s modulus: <200 MPa (ISO 527)
• Elongation at break: <200% (ISO 527)
• Notched Izod: >90 J/m (ISO 180)
• Shore hardness: D60 (ISO 868)

• Density: 1.0-1.2 g/cc at 25ºC (ISO 1675)
• Shrinkage: very low
• Viscosity: 40.000 mPas at 10ºC / 35.000 mPas at 15ºC / 25.000 mPas at 20ºC / 13.000 mPas at 30ºC / 4.400 mPas at 40ºC / 3.000 mPas at 50ºC / 2000 mPas at 60ºC / <1000 mPas at 70ºC

• Refractive index: 1.47-1.49 (ISO 489)

• Tough and foldable without breaking
• Non yellowing
• High impact and shattering resistance
• Properties similar to soft rubber with Shore D60 (ISO 868)
• Durable

• High viscous non flowing resin at room temperature
• Castable hot by gravity or by injection in molds
• Significant rigidity refinement can be done with our Hardness Adjusters 3Dresyn SA1 HV Bio and 3Dresyn HA1 HV MF Bio
• Detailed rigidity refinement can be done with our Hardness Adjusters 3Dresyn SA2 LV Bio and 3Dresyn HA2 LV Bio
• Curable with light with Fine Tuners FT additives photo accelerants and/or
• Curable by heat with Fine Tuner TA1, our general purpose fast "Thermal Accelerant" for thermally curing our 3Dresyns

• Monomer Free
• Bio and synthetic resin source
• Organo-tin free

Final casting behavior, foldability, shattering resistance and mechanical performance must be validated by the user according to the intended application, curing route, mold design and processing conditions.

This material is supplied as a professional manufacturing material and is not marketed as a finished medical device. Final part performance and suitability must be validated by the user according to the intended application.

This technical datasheet should be used together with the relevant processing, calibration, safety and workflow documentation available in the 3Dresyns® Resources section.
